Sony SA-VE322 - PRINTED WIRING BOARD - MAIN Section (SA-WMS325); Main Board

4
SA-VE322/VE325/WMS325/SS-CN325/V325
D101 E-5
D102 E-5
D103 D-5
D104 D-5
D301 B-2
D302 B-2
D303 D-2
D304 D-2
D305 F-4
D306 H-3
D501 H-4
D502 D-3
D503 D-3
D701 F-5
D702 F-5
D703 F-4
D704 G-4
IC101 D-5
IC102 B-5
IC103 B-4
IC104 F-5
IC701 G-5
Q101 B-5
Q102 A-5
Q103 A-4
Q104 A-4
Q301 D-2
Q302 C-2
Q303 C-2
Q304 C-3
Q305 C-3
Q306 D-2
Q307 D-3
Q308 F-2
Q309 E-2
Q310 F-2
Q311 F-2
Q701 F-5
Q702 F-5
Q703 H-5
Q704 H-5
Q705 H-5
1-2. PRINTED WIRING BOARD – MAIN Section (SA-WMS325) –
• See page 3 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
MAIN BOARD
J101
OUT
OUT
IN
LINE
SPEAKER
TM101
IN
L
R
+
+
+
+
––
––
POWER SAVE
AUTO
OFF
S701
(11)
11
1-680-777-
T501
POWER
TRANSFORMER
SP1
A
CONNECTOR BOARD
CN202
E
AUTO POWER
BOARD
CN604
B
POWER BOARD
CN401
C
AUTO POWER
BOARD
CN605
D
POWER SWITCH
BOARD
CN801
A
B
C
D
E
F
G
H
I
J
K
L
1 2 3 4 5 6
IC102
IC103
IC101
IC104
IC701
(Page 7)
(Page 7)
(Page 8)
(Page 8)
(Page 8)
