Sony SA-VE322 - PRINTED WIRING BOARDS - POWER Section (SA-WMS325); Power Switch Board

8
SA-VE322/VE325/WMS325/SS-CN325/V325
T601
POWER
TRANSFORMER
VOLTAGE
SELECTOR
S601
220-240V
110-120V
(11)
11
1-680-783-
AUTO POWER BOARD
AC IN
POWER
S1
POWER SWITCH BOARD
(11)
11
1-680-780-
C
MAIN
BOARD
CN502
E
MAIN
BOARD
CN501
D
MAIN
BOARD
CN701
C5
(EXCEPT SP)
(SP)
D801
ON/STANDBY
(EXCEPT SP)
(EXCEPT SP)
RY601
(SP)
A
B
C
D
E
F
G
H
I
1 2 3 4
1-6. PRINTED WIRING BOARDS – POWER Section (SA-WMS325) –
• See page 3 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D601 A-2
D602 A-2
D603 A-2
D604 A-2
D605 A-3
D606 A-4
D607 C-1
D608 B-4
D801 G-2
Q601 B-4
Q602 A-4
(Page 4)
(Page 4)
(Page 4)
