Sony SA-VE322 - PRINTED WIRING BOARDS - CONTROL Section (SA-WMS325); Connector Board; Control Board; Power Board

7
SA-VE322/VE325/WMS325/SS-CN325/V325
CONNECTOR BOARD
CONTROL
BOARD
MODE BOARD
POWER BOARD
(11)
11
1-680-781-
(11)
11
1-680-782-
A
B
MAIN
BOARD
CN101
MAIN
BOARD
CN301
(11)
11
1-680-778-
LEVEL
(11)
11
1-680-779-
S901
MOVIE
R
MUSIC
MODE
A
B
C
D
E
F
G
1 2 3 4 5 6
IC201
1-5. PRINTED WIRING BOARDS – CONTROL Section (SA-WMS325) –
• See page 3 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
IC201 B-5
Q401 F-4
Q402 F-4
Q403 F-2
Q404 F-5
(Page 4)
(Page 4)
