SA-VE445H/WMS445/SS-MS445
Ref. No. Part No. Description Remark
R710 1-249-421-11 CARBON 2.2K 5% 1/4W
R711 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
RY301 1-515-920-11 RELAY (24V)
< SWITCH >
S701 1-771-188-11 SWITCH, SLIDE (POWER SAVE)
< TERMINAL >
TM101 1-537-737-11 TERMINAL BOARD (SPEAKER) (US,CND)
*************************************************************
1-680-786-11 POWER BOARD
*************
< CAPACITOR >
C401 1-126-947-11 ELECT 47uF 20% 16V
< CONNECTOR >
* CN401 1-564-243-11 PIN, CONNECTOR (3.96mm PITCH) 6P
< TRANSISTOR >
Q401 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q402 8-729-119-77 TRANSISTOR 2SA1175-FEK
0 Q403 8-749-010-25 TRANSISTOR MN2488-OPY-M
0 Q404 8-749-010-26 TRANSISTOR MP1620-OPY-M
< RESISTOR >
R401 1-249-437-11 CARBON 47K 5% 1/4W
R402 1-249-421-11 CARBON 2.2K 5% 1/4W
R403 1-249-414-11 CARBON 560 5% 1/4W
0 R404 1-249-408-11 CARBON 180 5% 1/4W
0 R405 1-249-408-11 CARBON 180 5% 1/4W
0 R406 1-217-151-00 METAL 0.22 10% 2W F
0 R407 1-217-151-00 METAL 0.22 10% 2W F
*************************************************************
1-680-787-11 POWER SWITCH BOARD
********************
< CAPACITOR >
0 C1 1-113-924-11 CERAMIC 0.0047uF 20% 250V
< CONNECTOR >
* CN1 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< SWITCH >
0 S1 1-554-920-61 SWITCH, PUSH (AC POWER) (1 KEY) (POWER)
*************************************************************
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
POWER POWER SWITCH
MISCELLANEOUS
***************
0 57 1-696-845-31 CORD, POWER (AUS)
0 57 1-769-744-52 CORD, POWER (SP,MY)
0 57 1-783-531-11 CORD, POWER (US,CND)
107 1-694-516-21 TERMINAL, SPEAKER
0 F601 1-532-463-31 FUSE (T1AL/250V) (AUS)
0 F601 1-532-501-31 FUSE (T0.8AL/250V) (SP,MY)
0 F601 1-533-418-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(2.5A/125V) (US,CND)
0 F602 1-532-503-31 FUSE (T1.6AL/250V) (SP,MY)
SP1 1-529-296-12 SPEAKER (20cm) (WOOFER) (SA-WMS445)
(AUS,SP,MY)
SP1 1-825-151-11 SPEAKER (20cm) (WOOFER) (SA-WMS445)
(US,CND)
SP2 1-825-313-11 SPEAKER (5.7cm) (WOOFER) (SA-MS445)
SP3 1-825-313-11 SPEAKER (5.7cm) (WOOFER) (SA-MS445)
SP4 1-825-314-11 SPEAKER (2.5cm) (TWEETER) (SA-MS445)
0 T501 1-435-999-11 TRANSFORMER, POWER (US,CND)
0 T501 1-437-219-12 TRANSFORMER, POWER (SP,MY)
0 T501 1-437-246-11 TRANSFORMER, POWER (AUS)
0 T601 1-435-993-11 TRANSFORMER, POWER (US,CND)
0 T601 1-435-994-11 TRANSFORMER, POWER (AUS)
0 T601 1-435-995-11 TRANSFORMER, POWER (SP,MY)
*************************************************************
ACCESSORIES
************
1-751-598-53 CORD, CONNECTION (PIN-PIN)
1-790-503-12 CORD, SPEAKER (10m)
1-790-503-32 CORD, SPEAKER (3.5m)
4-246-138-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,
SPANISH) (US,CND,AUS)
4-246-138-51 MANUAL, INSTRUCTION (ENGLISH,FRENCH,
SPANISH,TRADITIONAL CHINESE)
(SP,MY)
4-972-322-01 FOOT (Y) (EXCEPT AUS)
