13
SA-VE835ED/WMS835/SS-MS835
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
POWER SWITCH
< COIL >
FB901 1-412-473-21 INDUCTOR (SMALL TYPE)
< IC >
IC901 6-700-162-01 IC STR-F6426S (US,CND,MX)
IC901 8-749-017-79 IC STR-F6676 (AEP,UK,SP,AR,KR)
IC902 8-749-019-49 IC SE040
IC906 8-759-604-39 IC M5F78M12L
IC907 8-759-604-45 IC M5F79M12L
< COIL >
0 L901 1-416-778-11 FILTER, LINE (AEP,UK,SP,AR,KR)
0 L901 1-424-978-11 FILTER, LINE (US,CND,MX)
0 L902 1-416-778-11 FILTER, LINE (AEP,UK,SP,AR,KR)
0 L902 1-424-977-11 TRANSFORMER, LINE FILTER (US,CND,MX)
L903 1-419-667-11 COIL, CHOKE 10uH
L904 1-410-334-21 INDUCTOR 100uH
L905 1-410-334-21 INDUCTOR 100uH
< PHOTO COUPLER >
PC901 8-749-019-04 PHOTO COUPLER TLP421
< TRANSISTOR >
Q701 8-729-029-86 TRANSISTOR DTC124ESA
Q703 8-729-178-42 TRANSISTOR 2SC2784-F
Q704 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q705 8-729-029-86 TRANSISTOR DTC124ESA
Q901 8-729-111-29 TRANSISTOR 2SD1616A-K
< RESISTOR >
0 R701 1-215-869-11 METAL OXIDE 1K 5% 1W F
R702 1-247-887-00 CARBON 220K 5% 1/4W
R703 1-249-441-11 CARBON 100K 5% 1/4W
R704 1-249-433-11 CARBON 22K 5% 1/4W
R705 1-249-441-11 CARBON 100K 5% 1/4W
R706 1-249-441-11 CARBON 100K 5% 1/4W
R707 1-249-427-11 CARBON 6.8K 5% 1/4W
R708 1-249-427-11 CARBON 6.8K 5% 1/4W
R709 1-249-433-11 CARBON 22K 5% 1/4W
0 R901 1-202-725-00 SOLID 3.3M 10% 1/2W F
(US,CND,MX)
0 R902 1-202-725-00 SOLID 3.3M 10% 1/2W F
(AEP,UK,SP,AR,KR)
R903 1-247-903-00 CARBON 1M 5% 1/4W
0 R904 1-215-901-00 METAL OXIDE 33K 5% 2W F
(US,CND,MX)
0 R904 1-218-642-11 METAL OXIDE 100K 5% 1W F
(AEP,UK,SP,AR,KR)
R905 1-247-895-00 CARBON 470K 5% 1/4W
R906 1-260-083-11 CARBON 47 5% 1/2W
R907 1-249-429-11 CARBON 10K 5% 1/4W
R908 1-249-393-11 CARBON 10 5% 1/4W
R909 1-249-421-11 CARBON 2.2K 5% 1/4W
0 R910 1-240-858-11 METAL 0.27 5% 2W F
(AEP,UK,SP,AR,KR)
0 R910 1-244-317-71 METAL 0.18 5% 2W F
(US,CND,MX)
0 R911 1-219-984-51 METAL 0.1 5% 2W F
(US,CND,MX)
0 R911 1-244-398-71 METAL 0.3 5% 2W F
(AEP,UK,SP,AR,KR)
R912 1-249-415-11 CARBON 680 5% 1/4W
R913 1-249-426-11 CARBON 5.6K 5% 1/4W
R914 1-249-419-11 CARBON 1.5K 5% 1/4W
R915 1-249-417-11 CARBON 1K 5% 1/4W
R916 1-249-420-11 CARBON 1.8K 5% 1/4W
0 R917 1-249-381-11 CARBON 1 5% 1/4W F
0 R918 1-249-381-11 CARBON 1 5% 1/4W F
< RELAY >
RY701 1-515-920-11 RELAY (24V)
< THERMISTOR >
0 THP901 1-803-916-11 THERMISTOR, NTC
*************************************************************
A-4728-653-A POWER SWITCH BOARD, COMPLETE
******************************
< CAPACITOR >
0 C1 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
* CN801 1-770-314-11 PIN, CONNECTOR 2P
< SWITCH >
0 S801 1-554-920-11 SWITCH, PUSH (AC POWER) (1 KEY) (POWER)
*************************************************************
MAIN POWER
Ver 1.1
