10
SA-WMSP68
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
D502 8-719-991-33 DIODE 1SS133T-77
D601 8-719-991-33 DIODE 1SS133T-77
< GROUND TERMINAL >
G1 1-537-738-21 TERMINAL, GROUND
G2 1-537-738-21 TERMINAL, GROUND
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-178-42 TRANSISTOR 2SC2784-F
Q503 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q504 8-729-029-86 TRANSISTOR DTC124ESA
< RESISTOR >
R401 1-249-393-11 CARBON 10 5% 1/4W
0R402 1-219-153-11 FUSIBLE 10 5% 1/4W F
0R403 1-219-153-11 FUSIBLE 10 5% 1/4W F
0R404 1-215-892-11 METAL OXIDE 1K 5% 2W F
0R405 1-215-892-11 METAL OXIDE 1K 5% 2W F
R500 1-249-421-11 CARBON 2.2K 5% 1/4W
R501 1-249-429-11 CARBON 10K 5% 1/4W
R502 1-247-871-11 CARBON 47K 5% 1/4W
R503 1-247-879-11 CARBON 100K 5% 1/4W
R504 1-247-879-11 CARBON 100K 5% 1/4W
R505 1-247-863-11 CARBON 22K 5% 1/4W
R506 1-247-831-11 CARBON 1K 5% 1/4W
0R507 1-215-868-00 METAL OXIDE 680 5% 1W F
R508 1-247-863-11 CARBON 22K 5% 1/4W
0R601 1-215-920-11 METAL OXIDE 3.3K 5% 3W F
< RELAY >
RY501 1-515-920-11 RELAY (24V)
*************************************************************
A-4751-957-A POWER AMP BOARD, COMPLETE
***************************
< CAPACITOR >
C301 1-126-967-11 ELECT 47uF 20% 50V
C302 1-126-967-11 ELECT 47uF 20% 50V
C303 1-128-813-11 CERAMIC 220PF 5% 50V
C304 1-126-964-11 ELECT 10uF 20% 50V
C305 1-104-658-11 ELECT 100uF 20% 10V
C306 1-128-813-11 CERAMIC 220PF 5% 50V
C307 1-126-968-11 ELECT 100uF 20% 50V
C308 1-126-968-11 ELECT 100uF 20% 50V
C309 1-162-199-31 CERAMIC 10PF 5% 50V
C310 1-126-964-11 ELECT 10uF 20% 50V
C311 1-126-967-11 ELECT 47uF 20% 50V
C312 1-128-813-11 CERAMIC 220PF 5% 50V
C313 1-126-964-11 ELECT 10uF 20% 50V
C314 1-136-165-00 FILM 0.1uF 5% 50V
C315 1-136-165-00 FILM 0.1uF 5% 50V
C316 1-128-813-11 CERAMIC 220PF 5% 50V
< CONNECTOR >
CN302 1-818-593-11 PLUG, CONNECTOR 13P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
D303 8-719-991-33 DIODE 1SS133T-77
< IC >
IC301 6-600-091-01 IC STK404-130S
< TRANSISTOR >
Q301 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q302 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
< RESISTOR >
R301 1-247-847-11 CARBON 4.7K 5% 1/4W
R302 1-247-863-11 CARBON 22K 5% 1/4W
R303 1-247-847-11 CARBON 4.7K 5% 1/4W
R304 1-249-429-11 CARBON 10K 5% 1/4W
R305 1-247-863-11 CARBON 22K 5% 1/4W
R307 1-247-871-11 CARBON 47K 5% 1/4W
R308 1-249-413-11 CARBON 470 5% 1/4W
R309 1-249-411-11 CARBON 330 5% 1/4W
0 R310 1-217-637-00 FUSIBLE 1 5% 1/4W F
0 R311 1-215-886-11 METAL OXIDE 100 5% 2W F
R312 1-247-871-11 CARBON 47K 5% 1/4W
R313 1-247-847-11 CARBON 4.7K 5% 1/4W
R314 1-247-847-11 CARBON 4.7K 5% 1/4W
R315 1-249-393-11 CARBON 10 5% 1/4W
0 R316 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R317 1-247-847-11 CARBON 4.7K 5% 1/4W
R318 1-247-850-11 CARBON 6.2K 5% 1/4W
R319 1-249-429-11 CARBON 10K 5% 1/4W
*************************************************************
POWER TRANS BOARD
*******************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
0 C1 1-113-924-11 CERAMIC 0.0047uF 20% 250V
< CONNECTOR >
CN1 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN2 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
*************************************************************
SWITCH BOARD
*************
< CAPACITOR >
0 C901 1-113-924-11 CERAMIC 0.0047uF 20% 250V
< CONNECTOR >
CN502 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CN901 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
MAIN POWER AMP POWER TRANS SWITCH
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
