REPLACEMENT PARTS LIST
SDM-E76A/D
Ref. No. SONY Part No. SONY name
X21099921 BEZEL ASSY (E76D)
X21480871 BEZEL ASSY (E76A)
178959421 Mounted PWB, H (Key board for E76A)
178959411 Mounted PWB, H (Key board for E76D)
180216611 Panel: CLAA170EA07Q (CPT)
180216711 Panel: M170E5-L09 (CMO)
178959011 Mounted PWB, A (Main board) (E76D for CPT)
178959111 Mounted PWB, A (Main board) (E76A for CPT)
178959021 Mounted PWB, A (Main board) (E76D for CMO)
178959121 Mounted PWB, A (Main board) (E76A for CMO)
178959211 Mounted PWB, G (Power board) (for CPT)
178958811 Mounted PWB, G (Power board) (for CMO)
6 191002683 Connector Assy (Panle link cable)
7 X21099941 HINGE ASSY
8 268576501
Rubber, Front Foot
(Only 1 piece)
(Only 1 piece)
9 268576601 STAND
268576901 SHIELD, REAR (E76D)
268576911 SHIELD, REAR (E76A)
11 268575901 CABINET, REAR
12 268576101 MULTI BUTTON
13 268576201 FRONT POWER BUTTON
14 269348001
HEXAGON SCREW
ACCESSORIES & PACKING MATERIALS
182984911 POWER CORD, BLACK (AEP)
182984811 POWER CORD, BLACK (U/C)
183086221 POWER CORD, BLACK (WB)
183344411 POWER CORD, BLACK (CH)
16 182985511 DVI CABLE
17 182987611 D-SUB CABLE
268147621 QUICK SETUP GUIDE (AEP)
268147611 QUICK SETUP GUIDE (U/C,WB)
19 268595601 CD-ROM
1
2
3
5
10
4
18
15
※Please refer to the following URL of TV QA web page to see the latest service parts list.
http://www.tvdg.sony.co.jp/cs/sdm-pn/index.html
