Sony SDM-HS74 - Exploded View Parts List

- 18 -
EXPLODED VIEW PARTS LIST
1
2
3
4-1
4-2
5
6
7
8
9
10
11
12
13
14
15
16
3091TKL061K CABINET ASSEMBLY, HS94 SONY 3090TKL061A BLUE - Europe, U.S.A/CANADA-SDM-HS74
3091TKL061L
CABINET ASSEMBLY, HS74 SONY 3090TKL061A BLACK - U.S.A/CANADA-SDM-HS74, SDM-HS74P
3091TKL061N CABINET ASSEMBLY, HS74P SONY 3090TKL061A BLACK SPRAY - Europe, Japan - SDM-HS74P
3091TKL061M
CABINET ASSEMBLY, HS74P SONY 3090TKL061A SILVER SPRAY - Europe, Japan,U.S.A/CANADA-SDM-HS74P
6304FCI005B LCD(LIQUID CRYSTAL DISPLAY), M170E5-L05 CHIMEI TFT COLOR 300NITS 16MS TCO-03 TN SXGA - Europe-SDM-HS74
6304FAU012A LCD(LIQUID CRYSTAL DISPLAY), M170EN05V5 AU TFT COLOR SXGA 250NIT GEN5-Europe, U.S.A/CANADA-SDM-HS74
6304FAU010B
LCD(LIQUID CRYSTAL DISPLAY), M170EN06-V2(AR COATING), AU TFT COLOR LVDS SXGA 16MS - SDM-HS74P
3809TKL085C BACK COVER ASSEMBLY, HS74 3808TKL084A BLACK-SDM-HS74P, U.S.A/CANADA-SDM-HS74
3809TKL085B BACK COVER ASSEMBLY, HS74 3808TKL084A DARK BLUE -SDM-HS74
3043TKK109A TILT SWIVEL ASSEMBLY, SONY_HS17 . . - SDM-HS74
3043TKK109C TILT SWIVEL ASSEMBLY, SONY HS74P . .- SDM-HS74P
3043TKK115B TILT SWIVEL ASSEMBLY, HS74 3550TKK304C _NT - SDM-HS74
3043TKK115C TILT SWIVEL ASSEMBLY, HS74P 3550TKK304C .- SDM-HS74P
6871TST540B PWB(PCB) ASSEMBLY,SUB, LHS74/94(P)M CONTROL TOTAL SONY CL-55
4951TKS165B METAL ASSEMBLY, FRAME HS74 CMO_L05 - SDM-HS74
4951TKS165A METAL ASSEMBLY, FRAME HS74 AUO_V5 - SDM-HS74
4951TKS165D METAL ASSEMBLY, FRAME HS74 AUO EN06 V2 - SDM-HS74P
4950TKK583A METAL, FIX CONNECTOR CMO 17 OX73
4950TKK487A METAL, FIX CONNECTOR-AU SIDE LS71K
3550TKK301B COVER, LHS73K PIECE BACK DARK BLUE - SDM-HS74
3550TKK301G COVER, LHS73K PIECE BACK BLACK - SDM-HS74(USA/CANADA), SDM-HS74P
6631T11016W CONNECTOR ASSEMBLY, 30P-30P H-H 200MM UL20276 AWG30 LOX73L/LOX93L
6871TPT285C PWB(PCB) ASSEMBLY,POWER, HS74 CMO, HS94 LPL/AUO POWER TOTAL POWERNET
6871TPT285A PWB(PCB) ASSEMBLY,POWER, HS74 AUO 2X4PIN POWER TOTAL POWERNET
3313TL7047B MAIN TOTAL ASSEMBLY, LHS74M - AGRDR SONY CL-43 - SDM-HS74 , CMO
3313TL7047A MAIN TOTAL ASSEMBLY, LHS74/94PM _ AUO SONY CL-42 - SDM-HS74
3313TL7047E MAIN TOTAL ASSEMBLY, LHS74PM AURDR SONY CL-42 - SDM-HS74P, AUO
4815TKK040A SHIELD ASSEMBLY, REAR HS74
3550TKK302L COVER, HS74 BACK DECO BLUE- SDM-HS74
3550TKK302M COVER, HS74 BACK DECO BLACK- U.S.A/CANADA-SDM-HS74
- 3550TKK302P COVER, HS74P BACK DECO BLACK SPRAY - Europe, Japan-SDM-HS74P
3550TKK302N COVER, HS74P BACK DECO SILVER SPRAY- Europe, Japan, U.S.A/CANADA-SDM-HS74P
3550TKK302Q COVER, HS74P BACK DECO BLACK- U.S.A/CANADA-SDM-HS74P
3846TKK058B MARK, PIECE BADGE(AL),SONY-HS73-BK(3-704-176-51)
3846TKK062B MARK, PIECE BADGE SONY NO6.0(AL) 4-095-995-21 GREY
6620K00002G
SOCKET(CIRC),POWER, HUAJIE,SA-4S-008-2-AA(180MM),JST,17" SONY AC UNIVERSAL NOPIN BLACK
6631T20023L CONNECTOR ASSEMBLY, 11P-11P H-H 160MM UL1061 AWG26 TWI LOS93L (JST HOUSING)
Description Part No.
Ref. No.
