Sony SDM-HS74 - Replacement Parts List

- 19 -
DATE: 2004. 06. 02.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C204 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C205 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C206 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C207 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C208 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C209 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C210 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C211 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C213 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C214 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C215 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C216 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C217 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C218 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C219 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C220 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C221 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C222 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C223 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C224 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C225 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C226 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C227 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C230 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C231 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C232 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C233 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C240 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C251 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C500 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C501 0CZZTAT006A RV2-16V100MU-R ELNA 16V 10UF
C502 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C503 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C504 0CC330CK41A 33PF 1608 50V 5% R/TP NP0
C505 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C506 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C512 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C513 0CC100CK41A 10PF 1608 50V 5% R/TP NP0
C516 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C703 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C707 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C708 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C709 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C710 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C711 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C712 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C713 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C714 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C727 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C730 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C731 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C732 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
DATE: 2004. 06. 02.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C733 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C734 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C735 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C737 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C738 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C739 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C740 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C745 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C746 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C747 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C760 0CZZTAT005B RJ4-16V101MX ELNA 16V 100UF 2
C761 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C762 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C801 0CH3103K516 10000PF 50V 10% B(Y5P) 2012 R
C802 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C803 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C804 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C809 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C810 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C817 0CZZTAT005B RJ4-16V101MX ELNA 16V 100UF 2
C818 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C819 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C820 0CZZTAT005B RJ4-16V101MX ELNA 16V 100UF 2
C821 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C822 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C823 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C828 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C829 0CH3103K516 10000PF 50V 10% B(Y5P) 2012 R
C831 0CZZTAT005B RJ4-16V101MX ELNA 16V 100UF 2
C832 0CZZTAT005B RJ4-16V101MX ELNA 16V 100UF 2
D701 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D702 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D706 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D707 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
D708 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D709 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D710 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D711 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D712 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D713 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D714 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D715 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D719 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
D720 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D721 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D722 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D723 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D724 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D725 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D726 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
D727 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
DIODEs
