EXPLODED VIEW PARTS LIST
Ref. No. Part No. Description
1
X-2050-648-1 BEZEL ASSY (Silver)
X-2050-830-1 BEZEL ASSY (Black)
22-588-346-11 BUTTON BRAKET
32-588-343-11 MULTI BUTTON
4 2-588-344-01 POWER BUTTON
5
1-805-818-11 LCD PANEL (LPL)
1-805-811-11 LCD PANEL FLC48SXC8V-12A (Fujitsu)
6
1-789-179-11 MOUNTED PWB, G (LPL)
1-789-178-11 MOUNTED PWB, G (Fujitsu)
7
1-789-180-11 MOUNTED PWB, A (LPL)
1-789-188-11 MOUNTED PWB, A (Fujitsu)
81-789-187-11 MOUNTED PWB, H (COMMON)
9 1-900-275-71 CONNECTOR ASSY
10 X-2050-652-1 STAND ASSY
11 X-2050-654-1 HINGE ASSY
12 X-2050-650-1 BACK CABINET ASSY
13
2-588-893-01 REAR COVER (Silver)
2-588-893-11 REAR COVER (Black)
14 2-591-627-01 SCREW COVER
15 1-819-276-11 AC INLET
16 2-588-347-01 METAL BRAKET
17 2-591-628-01 FRONT FOOT RUBBER
18 2-593-157-01 RUBBER BUSHIMG
ACCESSORIES & PACKING MATERIALS
1-827-118-11 POWER-SUPPLY CORD SET (U/C), Black
19 1-827-120-11 POWER-SUPPLY CORD SET (AEP), Black
1-827-122-11 POWER-SUPPLY CORD SET (CH), Black
20 1-827-757-11 D-SUB CABLE
21 1-827-758-11 DVI CABLE
22 4-102-356-21 CD-ROM
23
2-583-748-01 QUICK SETUP GUIDE (U/C)
2-583-748-11 QUICK SETUP GUIDE (AEP, CH)
