Sony SDM-HS95P - Product Specifications; Display Characteristics; Power, Environment, Dimensions, and Weight

– 3 –
SDM-HS95P (E)
1. LCD CHARACTERISTICS
Type : TFT Color LCD Module
Active Display Area : 19 inch(376.32(H) x 301.056(V))
Size : 404.2(W) x 330(H) x 20(D)
Pixel Pitch : (0.098 x 3) x 0.294
Color Depth : 16.2M Colors
Electrical Interface : LVDS
Surface Treatment : Glare
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio 10
LPL TN
Right : +70°(Min.), +80°(TYP) Left : +70°(Min.), +80°(TYP)
Top :+75° min., +85°(Typ) Bottom : +65°min., +75°(Typ)
FUJITSU
Right : +85°(Min.) Left : +89°(TYP)
Top : +85°(Min.) Bottom : +89°(TYP)
2-2. Luminance : 450(Typ)
2-3. Contrast Ratio : 600(Typ)
3. SIGNAL (Refer to the Timing Chart)
3-1. Sync Signal
• Type : Separate Sync
3-2. Video Input Signal
1) Type : R, G, B Analog
2) Voltage Level : 0~0.70 V(±
5%)
3) Input Impedance : 75
Ω
3-3. Operating Frequency
Horizontal(Analog): 28 ~ 80kHz
Horizontal(Digital) : 28 ~ 64kHz
Vertical(Analog) : 48 ~ 75Hz
Vertical(Digital) : 60Hz
4
. Max. Resolution
Analog : 1280 x 1024 / 75Hz
Digital : 1280 x 1024 / 60Hz
5. POWER SUPPLY
5-1. Power
: AC 100~240V, 50/60Hz , 1.0A
5-2. Power Consumption
6. ENVIRONMENT
6-1. Operating Temperature: 5°C~35°C (41°F~95°F)
(Ambient)
6-2. Relative Humidity : 10%~80%
(Non-condensing)
7. DIMENSIONS (with TILT/SWIVEL)
Width : 435 mm
Depth : 146 mm
Height : 418 mm
8. WEIGHT (with TILT/SWIVEL)
Net. Weight : 6.0 kg
Gross Weight : 8.41 kg
SPECIFICATIONS
MODE
POWER ON (NORMAL)
STAND-BY
SUSPEND
DPMS OFF
POWER S/W OFF
H/V SYNC
ON/ON
OFF/ON
ON/OFF
OFF/OFF
-
POWER CONSUMPTION
less than 60 W
less than 1 W
less than 1 W
less than 1 W
less than 1 W
LED COLOR
GREEN
AMBER
AMBER
AMBER
OFF
VIDEO
ACTIVE
OFF
OFF
OFF
-
CONTENTS
SPECIFICATIONS ................................................... 3
PRECAUTIONS ....................................................... 5
TIMING CHART ....................................................... 9
OPERATING INSTRUCTIONS .............................. 10
DISASSEMBLY ..................................................... 11
EXPLODED VIEW ...................................................13
EXPLODED VIEW PARTS LIST .............................14
