— 79 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PS
C121 1-136-165-00 FILM 0.1uF 5% 50V
C122 1-136-165-00 FILM 0.1uF 5% 50V
C133 1-162-303-11 CERAMIC 0.0033uF 20% 16V
C134 1-162-303-11 CERAMIC 0.0033uF 20% 16V
C135 1-162-303-11 CERAMIC 0.0033uF 20% 16V
C136 1-162-303-11 CERAMIC 0.0033uF 20% 16V
C137 1-162-294-31 CERAMIC 0.001uF 10% 50V
C138 1-162-303-11 CERAMIC 0.0033uF 20% 16V
C139 1-162-294-31 CERAMIC 0.001uF 10% 50V
C140 1-162-294-31 CERAMIC 0.001uF 10% 50V
C141 1-162-303-11 CERAMIC 0.0033uF 20% 16V
C142 1-162-303-11 CERAMIC 0.0033uF 20% 16V
C143 1-162-303-11 CERAMIC 0.0033uF 20% 16V
< CONNECTOR >
* CN203 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P
CN204 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
CN205 1-564-510-11 PLUG (MICRO CONNECTOR) 6P
CN301 1-564-510-11 PLUG (MICRO CONNECTOR) 6P
* CN302 1-564-243-11 PIN, CONNECTOR 6P
< DIODE >
D102 8-719-933-39 DIODE HZS6C1L
D103 8-719-933-39 DIODE HZS6C1L
D104 8-719-987-63 DIODE 1N4148M
D107 8-719-987-63 DIODE 1N4148M
D108 8-719-987-63 DIODE 1N4148M
D109 8-719-987-63 DIODE 1N4148M
D110 8-719-933-54 DIODE HZS9A2L
D111 8-719-933-54 DIODE HZS9A2L
D119 8-719-933-99 DIODE HZS22-1L
D120 8-719-933-39 DIODE HZS6C1L
D121 8-719-933-99 DIODE HZS22-1L
< EARTH >
* E3 1-537-738-21 TERMINAL, EARTH
< IC >
IC101 8-759-634-51 IC M5218AP
IC102 8-759-632-07 IC M5237L
IC103 8-759-245-79 IC TA79005S
< IC LINK >
! PS101 1-532-840-31 LINK, IC (PRF1250)(1.25A)(AEP,E,SP,MY,CH)
! PS102 1-532-839-31 LINK, IC (PRF1000)(1A)(AEP,E,SP,MY,CH)
< TRANSISTOR >
Q101 8-729-141-83 TRANSISTOR 2SB1094-LK
Q102 8-729-209-15 TRANSISTOR 2SD2012
Q103 8-729-141-83 TRANSISTOR 2SB1094-LK
Q104 8-729-141-83 TRANSISTOR 2SB1094-LK
Q105 8-729-119-78 TRANSISTOR 2SC2785-HFE
R957 1-216-025-91 METAL GLAZE 100 5% 1/10W
R958 1-216-073-00 METAL CHIP 10K 5% 1/10W
R959 1-216-073-00 METAL CHIP 10K 5% 1/10W
R960 1-216-073-00 METAL CHIP 10K 5% 1/10W
R961 1-216-073-00 METAL CHIP 10K 5% 1/10W
R962 1-216-073-00 METAL CHIP 10K 5% 1/10W
R963 1-216-073-00 METAL CHIP 10K 5% 1/10W
R964 1-216-073-00 METAL CHIP 10K 5% 1/10W
R965 1-216-073-00 METAL CHIP 10K 5% 1/10W
R966 1-216-073-00 METAL CHIP 10K 5% 1/10W
R967 1-216-073-00 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
RV301 1-241-393-21 RES, ADJ, METAL GLAZE 2.2K
RV901 1-241-393-21 RES, ADJ, METAL GLAZE 2.2K
< RELAY >
RY607 1-515-614-11 RELAY
RY608 1-515-614-11 RELAY
RY609 1-515-614-11 RELAY
RY610 1-515-614-11 RELAY
RY611 1-515-614-11 RELAY
RY612 1-515-614-11 RELAY
< VIBRATOR >
X201 1-767-496-11 VIBRATOR, CRYSTAL (16MHz)
X401 1-767-433-11 VIBRATOR, CRYSTAL (45.152MHz)
X901 1-767-434-11 VIBRATOR, CRYSTAL (18.432MHz)
X902 1-767-435-11 VIBRATOR, CRYSTAL (46.08MHz)
**************************************************************
* A-4398-191-A PS BOARD, COMPLETE (US,CND)
***************************
* A-4398-192-A PS BOARD, COMPLETE (AEP,E,SP,MY,CH)
*********************************
7-682-548-09 SCREW (3X8)
< CAPACITOR >
C104 1-126-023-11 ELECT 100uF 20% 25V
C105 1-126-023-11 ELECT 100uF 20% 25V
C106 1-126-027-11 ELECT 1000uF 20% 25V
C107 1-126-027-11 ELECT 1000uF 20% 25V
C111 1-126-964-11 ELECT 10uF 20% 50V
C112 1-126-927-11 ELECT 2200uF 20% 10V
C113 1-126-926-11 ELECT 1000uF 20% 10V
C114 1-126-963-11 ELECT 4.7uF 20% 50V
C117 1-126-967-11 ELECT 47uF 20% 50V
C118 1-126-967-11 ELECT 47uF 20% 50V
C119 1-164-046-11 CERAMIC 10PF 0.5PF 50V
C120 1-164-046-11 CERAMIC 10PF 0.5PF 50V
MAIN
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
