— 80 —
PS SW TR
* A-4398-190-A TR BOARD, COMPLETE
******************
< CONNECTOR >
CN703 1-695-092-11 SOCKET, CONNECTOR 7P
CN704 1-695-095-11 SOCKET, CONNECTOR 13P
< TRANSISTOR >
Q601 8-729-216-22 TRANSISTOR 2SA1162-G
Q602 8-729-230-49 TRANSISTOR 2SC2712-YG
Q603 8-729-216-22 TRANSISTOR 2SA1162-G
Q604 8-729-230-49 TRANSISTOR 2SC2712-YG
Q605 8-729-216-22 TRANSISTOR 2SA1162-G
Q606 8-729-230-49 TRANSISTOR 2SC2712-YG
Q607 8-729-216-22 TRANSISTOR 2SA1162-G
Q608 8-729-230-49 TRANSISTOR 2SC2712-YG
Q609 8-729-216-22 TRANSISTOR 2SA1162-G
Q610 8-729-230-49 TRANSISTOR 2SC2712-YG
Q611 8-729-216-22 TRANSISTOR 2SA1162-G
Q612 8-729-230-49 TRANSISTOR 2SC2712-YG
Q613 8-729-216-22 TRANSISTOR 2SA1162-G
Q614 8-729-230-49 TRANSISTOR 2SC2712-YG
Q615 8-729-216-22 TRANSISTOR 2SA1162-G
Q616 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R697 1-216-295-91 CONDUCTOR, CHIP (2012)
R698 1-216-045-00 METAL CHIP 680 5% 1/10W
R699 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R700 1-216-295-91 CONDUCTOR, CHIP (2012)
R701 1-216-045-00 METAL CHIP 680 5% 1/10W
R702 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R703 1-216-295-91 CONDUCTOR, CHIP (2012)
R704 1-216-045-00 METAL CHIP 680 5% 1/10W
R705 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R706 1-216-295-91 CONDUCTOR, CHIP (2012)
R707 1-216-045-00 METAL CHIP 680 5% 1/10W
R708 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R709 1-216-295-91 CONDUCTOR, CHIP (2012)
R710 1-216-045-00 METAL CHIP 680 5% 1/10W
R711 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R712 1-216-295-91 CONDUCTOR, CHIP (2012)
R713 1-216-045-00 METAL CHIP 680 5% 1/10W
R714 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R715 1-216-013-00 METAL CHIP 33 5% 1/10W
R716 1-216-045-00 METAL CHIP 680 5% 1/10W
R717 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R718 1-216-013-00 METAL CHIP 33 5% 1/10W
R719 1-216-045-00 METAL CHIP 680 5% 1/10W
R720 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R739 1-216-073-00 METAL CHIP 10K 5% 1/10W
Q106 8-729-209-15 TRANSISTOR 2SD2012
Q107 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q108 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R101 1-249-409-11 CARBON 220 5% 1/4W F
(AEP,E,SP,MY,CH)
R101 1-249-417-11 CARBON 1K 5% 1/4W F
(US,CND)
R102 1-249-409-11 CARBON 220 5% 1/4W F
(AEP,E,SP,MY,CH)
R102 1-249-417-11 CARBON 1K 5% 1/4W F
(US,CND)
R103 1-247-843-11 CARBON 3.3K 5% 1/4W
R104 1-247-843-11 CARBON 3.3K 5% 1/4W
R105 1-249-429-11 CARBON 10K 5% 1/4W
R106 1-249-429-11 CARBON 10K 5% 1/4W
R107 1-249-419-11 CARBON 1.5K 5% 1/4W F
R108 1-249-419-11 CARBON 1.5K 5% 1/4W F
R109 1-249-417-11 CARBON 1K 5% 1/4W F
R110 1-249-417-11 CARBON 1K 5% 1/4W F
R111 1-249-409-11 CARBON 220 5% 1/4W F
R113 1-247-843-11 CARBON 3.3K 5% 1/4W
R114 1-249-417-11 CARBON 1K 5% 1/4W F
! R115 1-217-153-00 METAL PLATE 0.47 10% 2W
! R116 1-217-153-00 METAL PLATE 0.47 10% 2W
R117 1-249-437-11 CARBON 47K 5% 1/4W
R119 1-249-421-11 CARBON 2.2K 5% 1/4W F
R120 1-249-429-11 CARBON 10K 5% 1/4W
R121 1-249-429-11 CARBON 10K 5% 1/4W
R122 1-249-417-11 CARBON 1K 5% 1/4W F
R123 1-249-417-11 CARBON 1K 5% 1/4W F
R124 1-249-411-11 CARBON 330 5% 1/4W
(AEP,E,SP,MY,CH)
R124 1-249-417-11 CARBON 1K 5% 1/4W F
(US,CND)
R125 1-249-411-11 CARBON 330 5% 1/4W
(AEP,E,SP,MY,CH)
R125 1-249-417-11 CARBON 1K 5% 1/4W F
(US,CND)
! R126 1-212-865-00 FUSIBLE 22 5% 1/4W F
**************************************************************
* 1-664-279-11 SW BOARD
********
< CONNECTOR >
CN4 1-564-321-00 PIN, CONNECTOR 2P
< SWITCH >
! S1 1-572-267-51 SWITCH, PUSH (AC POWER)(1 KEY)(POWER)
**************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
