— 81 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
VOLTR
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
R740 1-216-073-00 METAL CHIP 10K 5% 1/10W
R741 1-216-073-00 METAL CHIP 10K 5% 1/10W
R742 1-216-073-00 METAL CHIP 10K 5% 1/10W
R743 1-216-073-00 METAL CHIP 10K 5% 1/10W
R744 1-216-073-00 METAL CHIP 10K 5% 1/10W
R745 1-216-073-00 METAL CHIP 10K 5% 1/10W
R746 1-216-073-00 METAL CHIP 10K 5% 1/10W
R747 1-216-073-00 METAL CHIP 10K 5% 1/10W
R748 1-216-073-00 METAL CHIP 10K 5% 1/10W
R749 1-216-073-00 METAL CHIP 10K 5% 1/10W
R750 1-216-073-00 METAL CHIP 10K 5% 1/10W
R751 1-216-073-00 METAL CHIP 10K 5% 1/10W
R752 1-216-073-00 METAL CHIP 10K 5% 1/10W
R753 1-216-073-00 METAL CHIP 10K 5% 1/10W
R754 1-216-073-00 METAL CHIP 10K 5% 1/10W
R767 1-216-069-91 METAL CHIP 6.8K 5% 1/10W
R768 1-216-069-91 METAL CHIP 6.8K 5% 1/10W
R769 1-216-069-91 METAL CHIP 6.8K 5% 1/10W
R770 1-216-069-91 METAL CHIP 6.8K 5% 1/10W
R771 1-216-069-91 METAL CHIP 6.8K 5% 1/10W
R772 1-216-069-91 METAL CHIP 6.8K 5% 1/10W
**************************************************************
* 1-664-280-11 VOL BOARD
*********
< CAPACITOR >
C256 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
CN207 1-691-769-21 PLUG (MICRO CONNECTOR) 7P
< VARIABLE RESISTOR >
RV251 1-225-434-11 RES, VAR (WITH MOTOR) 10K/10K
(MASTER VOL)
**************************************************************
MISCELLANEOUS
*************
13 1-773-232-11 WIRE (FLAT TYPE)(25 CORE)
19 1-769-077-31 LEAD (WITH CONNECTOR)(2 CORE)(US,CND)
19 1-769-078-51 LEAD (WITH CONNECTOR)(2 CORE)
! 62 1-559-479-11 CORD, POWER (US,CND)
! 62 1-776-095-11 CORD, POWER (AEP,E,MY,SP,CH)
FL251 1-517-645-11 INDICATOR TUBE, FLUORESCENT
! T1 1-431-188-11 TRANSFORMER, POWER (US,CND)
! T1 1-431-189-11 TRANSFORMER, POWER (E,MY,SP,CH)
! T1 1-431-190-11 TRANSFORMER, POWER (AEP)
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-473-988-11 REMOTE COMMANDER (RM-EP9ES)
! 1-569-008-11 ADAPTOR, CONVERSION 2P (E,MY,SP,CH)
1-590-925-31 CORD, CONNECTION
3-859-365-11 MANUAL, INSTRUCTION
(ENGLISH,FRENCH)(US,CND,E,MY,SP,CH)
3-859-365-21 MANUAL, INSTRUCTION
(SPANISH,CHINESE)(E,MY,SP,CH)
3-859-365-31 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,SPANISH,PORTUGUESE)(AEP)
3-859-365-41 MANUAL, INSTRUCTION
(GERMAN,DUTCH,SWEDISH,ITALIAN)(AEP)
4-981-643-01 COVER, BATTERY (For RM-EP9ES)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-621-773-95 SCREW +B 2.6X6
#2 7-685-880-09 SCREW +BVTT 4X6 (S)
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#4 7-682-548-09 SCREW (3X8)
To Next Page
