Sony SDX420C - Mounting Dimensions (5.25 Drive)

9
For 5.25" Half Height (SDX-420C/R, SDX-520C/R)
(1.22±0.01 in)
31.0±0.3 mm
(1.65±0.01 in)
42.0±0.3 mm
(2.76±0.01 in)
70.0±0.3 mm
(1.87±0.01 in)
47.5±0.3 mm
(1.87±0.01 in)
47.5±0.3 mm
(3.12±0.01 in)
79.2±0.3 mm
(3.12±0.01 in)
79.2±0.3 mm
Cassette in ON point
The cartridge eject distance
(4±0.02 in)
101.6±0.5 mm
(0.61±0.02 in)
15.6±0.5 mm
(0.72±0.02 in)
18.4±0.5 mm
(1.41±0.02 in)
35.9±0.5 mm
(0.72±0.02 in)
18.2±0.5 mm
(1.35±0.02 in)
34.3±0.5 mm
(3.7±0.01 in)
94.0±0.3 mm
(1.61±0.04 in)
41.0±1.0 mm
(1.83±0.06 in)
46.5±1.5 mm
(1.62±0.02 in)
41.2±0.5 mm
(6.1±0.02 in)
155.0±0.5 mm
(0.3±0.02 in)
7.6±0.5 mm
(3.76 in)
95.5 mm
(5.75±0.02 in)
146±0.5 mm
(depth 0.10 in max.)
6-M3 (depth 2.5 mm max.)
(0.218±0.02 in)
5.53±0.5 mm
(0.333 in)
8.45 mm
(0.39±0.02 in)
9.9±0.5 mm
(0.86±0.02 in)
21.8±0.5 mm
(0.78±0.02 in)
19.7±0.5 mm
(2.26±0.04 in)
57.5±1 mm
(2.48±0.06 in)
63.0±1.5 mm
The cartridge eject distance
Cassette in ON point
4-M3
4-M3
(5.5±0.02 in)
139.6±0.5 mm
(0.28±0.02 in)
7±0.5 mm
(5.87±0.02 in)
149.0±0.5 mm
