Sony SLS-1A - Page 48

24
GB
Physical specifications
Enclosure
Cabinet: Extruded aluminum (powder coated)
Side/Back panel: Plastic
Grille
Punching metal steel plate (Painted)
Indicators
Status, Signal, LAN
Operating Temperature
Range (Ambient)
0 °C - 40 °C (32 °F - 104 °F)
Cooling System
Cooling is passive only
Environmental
Indoor only
Install
The installation angle can be adjusted either to 0 degree or to 10 degrees in the
horizontal direction by the supplied wall mounting bracket and speaker brackets.
Dimensions (w×h×d)
(approx.)
384 mm × 92 mm × 100 mm (15
1
/8 in × 3
5
/8 in × 4 in) (without speaker grille)
384 mm × 92 mm × 110 mm (15
1
/8 in × 3
5
/8 in × 4
3
/8 in) (with speaker grille)
Mass (approx.)
4 kg (8 lb 14 oz) (with speaker grille)
Included Accessories
Speaker grille (attached to the speaker) (1), Power cord (1),
Power cascade cable (Euro type terminal block) (1),
Ethernet cable for audio signal cascade (RJ-45) (1),
3-pin Euro type terminal block header (1), Speaker bracket (no slant) (2),
Speaker bracket (10-degree slant) (2), Speaker joint bracket (no slant) (1),
Speaker joint bracket (10-degree slant) (1), Wall mounting bracket (1),
Metal joint fitting for wall mounting brackets (1), Detachment stopper (2),
Metal joint fitting for attaching a safety wire (2), Cable clamp (2), Spacer pad A (2),
Spacer pad B (1), 4×10 screw with washer (9), Shoulder screw (2),
Operating Instructions (this manual) (1), Reference Guide (1), Warranty card (1)
