7-6
7-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• Abbreviation
CND: Canadian
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
DM-84
* A-6791-804-A DM-84 BOARD, COMPLETE
**********************
(Ref.No.:2,000 Series)
< JUMPER RESISTOR >
JR460 1-216-295-00 METAL CHIP 0 5% 1/10W
JR462 1-216-296-00 METAL CHIP 0 5% 1/8W
JR464 1-216-296-00 METAL CHIP 0 5% 1/8W
JR465 1-216-296-00 METAL CHIP 0 5% 1/8W
< RESISTOR >
R464 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R465 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R467 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R468 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R469 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R470 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R471 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R472 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R474 1-216-013-00 METAL CHIP 33 5% 1/10W
< SWITCH >
S462 1-762-196-21 SWITCH, TACT (EJECT)
S463 1-762-196-21 SWITCH, TACT (REC)
S465 1-762-196-21 SWITCH, TACT (REW)
S467 1-762-196-21 SWITCH, TACT (STOP)
S468 1-762-196-21 SWITCH, TACT (PLAY)
S469 1-762-196-21 SWITCH, TACT (FF)
S471 1-762-196-21 SWITCH, TACT (PAUSE)
************************************************************
* A-6791-802-A MA-341 BOARD, COMPLETE
***********************
(Ref.No.:1,000 Series)
* 3-951-893-01 HEAT SINK
* 3-960-273-01 SPACER, TOP END
* 3-960-274-01 SPACER, LED
* 3-966-865-01 BASE, INDICATION TUBE
3-970-608-21 SUMITITE (B3), +BV
< CAPACITOR >
C101 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C103 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C104 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C105 1-128-057-11 ELECT 330uF 20% 6.3V
C106 1-124-589-11 ELECT 47uF 20% 16V
C107 1-164-346-11 CERAMIC CHIP 1uF 16V
C108 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C109 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C111 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C112 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C113 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C115 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C116 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C140 1-124-584-00 ELECT 100uF 20% 10V
C141 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C142 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C143 1-128-131-11 ELECT 22uF 20% 50V
C144 1-128-131-11 ELECT 22uF 20% 50V
C145 1-126-935-11 ELECT 470uF 20% 6.3V
C146 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C160 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C161 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C162 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C163 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C164 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C165 1-163-102-00 CERAMIC CHIP 24PF 5% 50V
C166 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C167 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
C168 1-124-584-00 ELECT 100uF 20% 10V
C169 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C170 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C171 1-104-905-11 CAPACITOR 0.22F 5.5V
C172 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C173 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C176 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C201 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C202 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C203 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C204 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C205 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C206 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C207 1-163-241-11 CERAMIC CHIP 39PF 5% 50V
C208 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C209 1-124-589-11 ELECT 47uF 20% 16V
C210 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C211 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C213 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C214 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C215 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
