7-8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
C510 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C511 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C512 1-124-584-00 ELECT 100uF 20% 10V
C513 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C514 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C561 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C562 1-104-664-11 ELECT 47uF 20% 16V
C563 1-126-935-11 ELECT 470uF 20% 6.3V
! C600 1-104-705-11 FILM 0.1uF 20% 250V
! C601 1-113-920-11 CERAMIC 0.0022uF 20% 250V
C602 1-119-886-51 CERAMIC 470PF 10% 250V
! C603 1-119-911-51 CERAMIC 470PF 10% 250V
! C604 1-119-912-51 CERAMIC 1000PF 20% 250V
C605 1-119-882-51 ELECT(BLOCK) 120uF 20% 200V
C606 1-107-905-11 ELECT 4.7uF 20% 50V
C607 1-113-681-11 FILM 0.033uF 10% 400V
C608 1-162-558-11 CERAMIC 100PF 10% 2KV
C610 1-115-322-91 FILM 0.047uF 5% 50V
C611 1-115-322-91 FILM 0.047uF 5% 50V
C612 1-126-160-11 ELECT 1uF 20% 50V
C613 1-115-739-31 ELECT 0.0015F 20% 10V
C614 1-115-789-11 ELECT 0.001F 20% 25V
C615 1-126-967-11 ELECT 47uF 20% 50V
C616 1-126-941-11 ELECT 470uF 20% 25V
C617 1-126-935-11 ELECT 470uF 20% 16V
C618 1-126-967-11 ELECT 47uF 20% 50V
C619 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C620 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C621 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C622 1-128-131-11 ELECT 22uF 20% 50V
C623 1-124-589-11 ELECT 47uF 20% 16V
C624 1-124-589-11 ELECT 47uF 20% 16V
C625 1-104-664-11 ELECT 47uF 20% 16V
C626 1-126-965-11 ELECT 22uF 20% 50V
C627 1-126-965-11 ELECT 22uF 20% 50V
C628 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C629 1-124-234-00 ELECT 22uF 20% 16V
C638 1-126-925-11 ELECT 470uF 20% 10V
C639 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C642 1-126-967-11 ELECT 47uF 20% 50V
C650 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C701 1-104-664-11 ELECT 47uF 20% 16V
C706 1-126-963-11 ELECT 4.7uF 20% 50V
C707 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C709 1-126-933-11 ELECT 100uF 20% 16V
C710 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C712 1-126-933-11 ELECT 100uF 20% 16V
C980 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C981 1-124-589-11 ELECT 47uF 20% 16V
C982 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C984 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C985 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C986 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< JACK >
CJ561 1-779-011-11 JACK, PIN 6P (LINE-1 IN/LINE OUT)
< CONNECTOR >
CN101 1-779-724-11 CONNECTOR, BOARD TO BOARD 5P
CN102 1-779-723-11 CONNECTOR, BOARD TO BOARD 9P
* CN103 1-766-716-11 CONNECTOR, BOARD TO BOARD 3P
CN104 1-506-469-11 PIN, CONNECTOR 4P
CN161 1-506-468-11 PIN, CONNECTOR 3P
CN260 1-766-986-11 CONNECTOR, FFC/FPC 13P
* CN270 1-560-892-00 PIN, CONNECTOR 4P
CN301 1-506-469-11 PIN, CONNECTOR 4P
CN302 1-506-468-11 PIN, CONNECTOR 3P
* CN403 1-573-128-11 PIN, CONNECTOR 5P
CN404 1-506-475-11 PIN, CONNECTOR 10P
* CN423 1-573-128-11 PIN, CONNECTOR 5P
* CN600 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< JACK >
CNJ980 1-779-013-11 JACK, MINIATURE(CONTROL S OUT)
< DIODE >
D103 8-719-048-26 DIODE GL528V1
D109 8-719-200-82 DIODE 11ES2
D161 8-719-200-82 DIODE 11ES2
D162 8-719-200-82 DIODE 11ES2
D420 8-719-109-90 DIODE RD5.6ESB3
D561 8-719-110-08 DIODE RD8.2ES-B2
D600 8-719-051-93 DIODE DF06M-6031
D601 8-719-054-32 DIODE ERA15-06TP3
D602 8-719-058-91 DIODE AG01A-V0
D603 8-719-200-82 DIODE 11ES2
D604 8-719-109-62 DIODE RD3.0ES-B1
D605 8-719-911-19 DIODE 1SS119
D606 8-719-313-17 DIODE AU02A-V0
D607 8-719-022-97 DIODE D2S4MF
D608 8-719-073-18 DIODE S3L20UF34
D609 8-719-313-17 DIODE AU02A-V0
D610 8-719-160-64 DIODE RD16F-B1
D611 8-719-911-19 DIODE 1SS119
D612 8-719-109-85 DIODE RD5.1ES-B2
D618 8-719-911-19 DIODE 1SS119
D619 8-719-313-17 DIODE AU02A-V0
D702 8-719-150-92 DIODE RD33EB3T
D980 8-719-067-40 DIODE STZ6.8N-T146
D982 8-719-911-19 DIODE 1SS119
< EARTH >
ET600 1-537-770-21 TERMINAL BOARD, GROUND
ET601 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE >
! F600 1-533-296-11 FUSE, GLASS CYLINDRICAL(DIA.5)
< FERRITE BEAD >
FB101 1-414-235-22 INDUCTOR CHIP 0UH
FB601 1-410-858-21 INDUCTOR 0UH
