7-10
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
< COIL >
L101 1-414-930-21 INDUCTOR 2.2uH
L161 1-414-936-21 INDUCTOR 22uH
L162 1-414-936-21 INDUCTOR 22uH
L163 1-414-936-21 INDUCTOR 22uH
L201 1-414-946-21 INDUCTOR 39uH
L202 1-414-940-21 INDUCTOR 100uH
L203 1-414-934-21 INDUCTOR 10uH
L204 1-414-940-21 INDUCTOR 100uH
L205 1-414-940-21 INDUCTOR 100uH
L206 1-414-940-21 INDUCTOR 100uH
L270 1-414-940-21 INDUCTOR 100uH
L304 1-414-940-21 INDUCTOR 100uH
L328 1-410-071-11 INDUCTOR 10mH
L360 1-414-940-21 INDUCTOR 100uH
L420 1-414-936-21 INDUCTOR 22uH
L500 1-414-930-21 INDUCTOR 2.2uH
L501 1-414-940-21 INDUCTOR 100uH
L561 1-414-940-21 INDUCTOR 100uH
L601 1-403-588-11 INDUCTOR 22uH
L602 1-403-588-11 INDUCTOR 22uH
L603 1-410-509-11 INDUCTOR 10uH
L604 1-410-519-11 INDUCTOR 68uH
L605 1-414-142-11 INDUCTOR 1uH
L606 1-414-142-11 INDUCTOR 1uH
L703 1-414-930-21 INDUCTOR 2.2uH
L704 1-414-936-21 INDUCTOR 22uH
< LINE FILTER >
! LF600 1-416-929-11 FILTER, LINE
< FLUORECENT INDICATOR >
ND420 1-517-732-11 INDICATOR TUBE, FLUORESCENT
< PHOTO INTERUPTER >
! PH101 8-749-013-23 PHOTO INTERRUPTER GP3S120
! PH102 8-749-013-23 PHOTO INTERRUPTER GP3S120
! PH600 8-749-014-24 COUPLER, PHOTO ON3131-S(LF)
< IC LINK >
! PS101 1-532-727-11 LINK, IC 0.25A
! PS600 1-532-841-21 LINK, IC
< TRANSISTOR >
Q101 8-729-043-84 TRANSISTOR PT380F3
Q102 8-729-043-84 TRANSISTOR PT380F3
Q103 8-729-281-53 TRANSISTOR 2SC1815-GR
Q201 8-729-230-49 TRANSISTOR 2SC2712-YG
Q202 8-729-230-49 TRANSISTOR 2SC2712-YG
Q203 8-729-216-21 TRANSISTOR 2SA1162-Y
Q302 8-729-804-41 TRANSISTOR 2SB1122-S
Q303 8-729-821-15 TRANSISTOR 2SD1620
Q380 8-729-216-21 TRANSISTOR 2SA1162-Y
Q381 8-729-230-49 TRANSISTOR 2SC2712-YG
Q382 8-729-230-49 TRANSISTOR 2SC2712-YG
Q500 8-729-010-05 TRANSISTOR MSB709-RT1
Q502 8-729-216-21 TRANSISTOR 2SA1162-Y
Q561 8-729-010-05 TRANSISTOR MSB709-RT1
Q601 8-729-904-98 TRANSISTOR 2SC4054P
Q602 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
Q603 8-729-119-78 TRANSISTOR 2SC403SP-51
Q604 8-729-010-25 TRANSISTOR MSD601-RT1
Q604 8-729-422-29 TRANSISTOR 2SD601A-S
Q605 8-729-047-92 TRANSISTOR 2SB1398-Q(TA).S0
Q607 8-729-140-98 TRANSISTOR 2SD773-34
Q608 8-729-106-68 TRANSISTOR 2SD1615A-GP
< RESISTOR >
R101 1-249-413-11 CARBON 470 5% 1/4W F
R102 1-216-089-00 METAL CHIP 47K 5% 1/10W
R103 1-249-437-11 CARBON 47K 5% 1/4W
R104 1-216-081-00 METAL CHIP 22K 5% 1/10W
R105 1-247-863-91 CARBON 22K 5% 1/4W
R106 1-249-400-11 CARBON 39 5% 1/4W F
R107 1-249-400-11 CARBON 39 5% 1/4W F
R109 1-216-089-00 METAL CHIP 47K 5% 1/10W
R110 1-216-089-00 METAL CHIP 47K 5% 1/10W
R111 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R112 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R115 1-216-089-00 METAL CHIP 47K 5% 1/10W
R116 1-216-089-00 METAL CHIP 47K 5% 1/10W
R117 1-216-041-00 METAL CHIP 470 5% 1/10W
R118 1-216-089-00 METAL CHIP 47K 5% 1/10W
R119 1-216-077-00 METAL CHIP 15K 5% 1/10W
R120 1-249-417-11 CARBON 1K 5% 1/4W F
R121 1-216-041-00 METAL CHIP 470 5% 1/10W
R142 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R143 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R159 1-216-097-91 RES,CHIP 100K 5% 1/10W
R160 1-216-049-00 METAL CHIP 1K 5% 1/10W
R161 1-216-073-00 METAL CHIP 10K 5% 1/10W
R162 1-249-426-11 CARBON 5.6K 5% 1/4W
R163 1-216-049-00 METAL CHIP 1K 5% 1/10W
R164 1-216-089-00 METAL CHIP 47K 5% 1/10W
R165 1-216-089-00 METAL CHIP 47K 5% 1/10W
R166 1-216-073-00 METAL CHIP 10K 5% 1/10W
R167 1-249-431-11 CARBON 15K 5% 1/4W
R168 1-216-073-00 METAL CHIP 10K 5% 1/10W
R169 1-216-073-00 METAL CHIP 10K 5% 1/10W
R170 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R171 1-216-089-00 METAL CHIP 47K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R174 1-216-039-00 METAL CHIP 390 5% 1/10W
R175 1-216-041-00 METAL CHIP 470 5% 1/10W
R176 1-216-041-00 METAL CHIP 470 5% 1/10W
R177 1-216-041-00 METAL CHIP 470 5% 1/10W
R178 1-216-105-91 RES,CHIP 220K 5% 1/10W
R179 1-216-113-00 METAL CHIP 470K 5% 1/10W
MA-341
