Getting Started6
EN
SLV-P55EE/PH77EE 3-858-675-11 (2)
Step 3
Connecting the unit
to mains
1 Disconnect the aerial cable from your TV
and connect it to AERIAL IN on the rear
panel of the unit.
2 Connect AERIAL OUT of the unit and
the aerial input of your TV using the
supplied aerial cable.
3 Connect AC IN of the unit to the mains
using the supplied mains lead.
: Signal flow
Aerial cable
AC IN AERIAL IN
AERIAL OUT
AERIAL
OUT
IN
To Next Page
