Sony SPP-A946 - Page 49

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
– 63 –
C75 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C76 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C77 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C78 1-104-665-11 ELECT 100uF 20% 10V
C79 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C80 1-126-924-11 ELECT 330uF 20% 6.3V
C81 1-104-665-11 ELECT 100uF 20% 10V
C82 1-126-924-11 ELECT 330uF 20% 6.3V
C83 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C84 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C85 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C86 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C88 1-126-768-11 ELECT 2200uF 20% 16V
C89 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C90 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C91 1-126-934-11 ELECT 220uF 20% 10V
C92 1-126-934-11 ELECT 220uF 20% 16V
C93 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C94 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C95 1-104-664-11 ELECT 47uF 20% 25V
C97 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C98 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C99 1-126-964-11 ELECT 10uF 20% 50V
C101 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C102 1-126-934-11 ELECT 220uF 20% 16V
C103 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C104 1-126-924-11 ELECT 330uF 20% 10V
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C109 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
C110 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C113 1-126-924-11 ELECT 330uF 20% 10V
C114 1-126-924-11 ELECT 330uF 20% 10V
C115 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C116 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C119 1-126-767-11 ELECT 1000uF 20% 16V
C120 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C121 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C122 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C123 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C124 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C125 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C126 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
< TRIMMER >
CT1 1-141-373-11 CAP, TRIMMER 10PF
< DIODE >
D1 8-719-055-76 DIODE 1N4148
D2 8-719-055-76 DIODE 1N4148
D3 8-719-055-76 DIODE 1N4148
D4 8-719-910-75 DIODE HZ7B2L
D5 8-719-055-76 DIODE 1N4148
D6 8-719-055-76 DIODE 1N4148
D7 8-719-055-76 DIODE 1N4148
D8 8-719-915-61 DIODE HZ3.3EB1
D9 8-719-055-76 DIODE 1N4148
D10 8-719-055-76 DIODE 1N4148
D11 8-719-055-76 DIODE 1N4148
D12 8-719-109-71 DIODE RD3.9ES-B1
D13 8-719-055-76 DIODE 1N4148
D14 8-719-055-76 DIODE 1N4148
D15 8-719-910-68 DIODE HZ6C2L
D16 8-719-055-76 DIODE 1N4148
D17 8-719-055-76 DIODE 1N4148
D18 8-719-910-65 DIODE HZ6B2L
D19 8-719-055-76 DIODE 1N4148
D21 8-719-910-68 DIODE HZ6C2L
D22 8-719-055-76 DIODE 1N4148
D23 8-719-055-76 DIODE 1N4148
< CERAMIC FILTER >
FT1 1-760-143-42 FILTER, CERAMIC
FT2 1-527-569-00 FILTER, CERAMIC
< IC/PHOTO COUPLER >
IC1 8-759-089-92 IC IR3N74AN
IC2 8-719-018-90 PHOTO COUPLER LTV817-D
IC3 8-759-375-39 IC MC3361CD
IC4 8-759-510-71 IC BA10358F-E2
IC5 8-719-018-90 PHOTO COUPLER LTV817-D
IC6 8-759-510-71 IC BA10358F-E2
IC7 8-759-042-02 IC S80743AL-A7-S
IC8 8-759-666-27 IC MB89174APF-G-288-BND
< JACK/CONNECTOR >
J1 1-766-250-21 JACK, MODULAR (2C) 6P (LINE)
J2 1-580-727-11 JACK (DC IN 9V)
J3 1-770-650-11 CONNECTOR, FFC/FPC 22P
< RESISTOR >
JC3 1-216-864-11 METAL CHIP 0 5% 1/16W
JC117 1-216-864-11 METAL CHIP 0 5% 1/16W
JC129 1-216-864-11 METAL CHIP 0 5% 1/16W
JC148 1-216-296-00 SHORT 0
JC149 1-216-864-11 METAL CHIP 0 5% 1/16W
JC151 1-216-296-00 SHORT 0
< COIL >
L1 1-412-058-11 INDUCTOR CHIP 10uH
L2 1-412-056-11 INDUCTOR CHIP 4.7uH
L3 1-419-289-11 COIL, OSC
L4 1-412-056-11 INDUCTOR CHIP 4.7uH
L5 1-403-658-31 INDUCTOR 8.2nH
L6 1-410-324-11 INDUCTOR 4.7uH
L7 1-410-324-11 INDUCTOR 4.7uH
< TRANSISTOR >
Q1 8-729-200-87 TRANSISTOR 2SC2714-Y
Q2 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q3 8-729-216-22 TRANSISTOR 2SA1162-G
Q4 8-729-230-49 TRANSISTOR 2SC2712-YG
Q5 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6 8-729-120-28 TRANSISTOR 2SC1623-L5L6
BASE MAIN
