– 60 –
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BASE KEY
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
* A-3672-931-A BASE KEY BOARD, COMPLETE
************************
3-043-643-01 HOLDER (LED)
< CAPACITOR >
C201 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C202 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C203 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C204 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C205 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C206 1-124-779-00 TANTALUM CHIP 10uF 20% 16V
C207 1-124-779-00 TANTALUM CHIP 10uF 20% 16V
C208 1-162-979-11 CERAMIC CHIP 0.0027uF 10% 50V
C209 1-126-935-11 ELECT 470uF 20% 6.3V
C210 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C211 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C212 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C213 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C214 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C215 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C216 1-126-154-11 ELECT 47uF 20% 6.3V
C217 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C218 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C219 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C220 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C221 1-126-154-11 ELECT 47uF 20% 6.3V
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C223 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C224 1-126-154-11 ELECT 47uF 20% 6.3V
C225 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C226 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C227 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C228 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C229 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C230 1-117-370-11 CERAMIC CHIP 10uF 10V
C231 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C232 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C233 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C234 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C236 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C237 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C238 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C239 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C240 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C241 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C242 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C243 1-124-779-00 TANTALUM CHIP 10uF 20% 16V
C244 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C245 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C246 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C251 1-126-916-11 ELECT 1000uF 20% 6.3V
C252 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C253 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C254 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C255 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C257 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C258 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C259 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C260 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C270 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C271 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C272 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< DIODE >
D201 8-719-910-68 DIODE HZ6C2L
D202 8-719-055-76 DIODE 1N4148
D203 8-719-046-60 DIODE HZK6C
D204 8-719-910-68 DIODE HZ6C2L
D205 8-719-976-19 DIODE RLS-4148
D208 8-719-976-19 DIODE RLS-4148
D209 8-719-053-09 DIODE SML-310VTT86 (CHARGE)
D210 8-719-053-09 DIODE SML-310VTT86 (INTERCOM)
D211 8-719-053-09 DIODE SML-310VTT86 (SPEAKERPHONE)
D212 8-719-063-83 DIODE SML-510MWT86 (IN USE)
D213 8-719-079-32 DIODE LTL-94PURK-TA (ANSWER ON/OFF)
D214 8-719-074-30 DIODE SML-310LTT86 (MAIL BOX1)
D215 8-719-074-30 DIODE SML-310LTT86 (2)
D216 8-719-074-30 DIODE SML-310LTT86 (3)
D217 8-719-078-00 DIODE LTD-482P-03 (MESSAGE COUNTER)
D218 8-719-017-42 DIODE HSM88WA
D219 8-719-976-19 DIODE RLS-4148
D220 8-719-972-14 DIODE HZK6BL
< IC/SAW FILTER >
IC201 8-759-463-98 IC MC34119DR2
IC202 8-759-668-82 IC D16559UAC11AQC
To Next Page
