16
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SRF-H11
C34 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
< VARIABLE CAPACITOR >
CT1-1 1-141-524-12 CAP, VAR (FM FREQUENCY COVEREGE)
CT1-2 1-141-524-12 CAP, VAR (FM TRACKING)
CT1-3 1-141-524-12 CAP, VAR (AM FREQUENCY COVEREGE)
CT1-4 1-141-524-12 CAP, VAR (AM TRACKING)
CV1-1 1-141-524-12 CAP, VAR (TUNE)
CV1-2 1-141-524-12 CAP, VAR (TUNE)
CV1-3 1-141-524-12 CAP, VAR (TUNE)
CV1-4 1-141-524-12 CAP, VAR (TUNE)
< IC >
IC1 8-752-061-76 IC CXA1129N-T4
< COIL >
L1 1-412-965-11 INDUCTOR 68NH
L2 1-412-964-11 INDUCTOR 47NH
L3 1-428-309-11 COIL, AIR-CORE (FM TRACKING)
L4 1-428-308-11 COIL, AIR-CORE (FM 2nd OSC)
L5 1-406-467-11 COIL (OSC) (AM FREQUENCY COVEREGE)
L6 1-406-468-11 COIL (VCO) (FM VCO)
L7 1-501-940-21 ANTENNA, FERRITE-ROD (MW) (AM TRACKING)
L8 1-411-134-11 COIL, AIR-CORE (FM FREQUENCY COVEREGE)
L9 1-414-760-21 FERRITE 0uH
< TRANSISTOR >
Q1 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
< RESISTOR >
R1 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2 1-216-813-11 METAL CHIP 220 5% 1/10W
R3 1-216-813-11 METAL CHIP 220 5% 1/10W
R4 1-216-817-11 METAL CHIP 470 5% 1/10W
R5 1-216-797-11 METAL CHIP 10 5% 1/10W
R6 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7 1-216-821-11 METAL CHIP 1K 5% 1/10W
R8 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
S1 1-554-843-11 SWITCH, SLIDE (BAND)
******************************************************
ACCESSORIES
***********
3-249-181-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN, SPANISH, DUTCH, SWEDISH,
ITALIAN, PORTUGUESE, FINNISH)
MAIN
