Sony SRF-H11 - 4 Gear (Tuning Capacitor) Installation

7
SRF-H11
SECTION 4
Gear (tuning capacitor) installation
Note : Follow the installation procedure in the numerical order given.
1 Turn the PVC shaft all the way counterclockwise.
2 Set the gear (VC) onto the PVC shaft and secure it with screw.
PVC shaft
Gear (VC)
2 Screw
(1.7 x 3)
Main board
1
