15
Ref. No. Part No. Description Remarks
SRF-H11
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
•Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
* A-3347-939-A AUDIO BOARD, COMPLETE
********************
< CAPACITOR >
C101 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C102 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C103 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C104 1-126-153-11 ELECT 22uF 20% 6.3V
C105 1-124-257-00 ELECT 2.2uF 20% 50V
C106 1-124-257-00 ELECT 2.2uF 20% 50V
C107 1-115-156-11 CERAMIC CHIP 1uF 10V
C108 1-115-467-11 CERAMIC CHIP 0.22uF 10%10V
C109 1-124-259-11 ELECT 4.7uF 20% 16V
C110 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C112 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C114 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C115 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C116 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C117 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C118 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C119 1-124-259-11 ELECT 4.7uF 20% 16V
C120 1-124-434-00 ELECT 220uF 20% 4V
C122 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C123 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C124 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C125 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C126 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C127 1-126-157-11 ELECT 10uF 20% 16V
< IC >
IC101 6-701-831-01 IC TA2160FN(EL)
< TRANSISTOR >
Q101 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
< RESISTOR >
R106 1-216-849-11 METAL CHIP 220K 5% 1/10W
R107 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R108 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R109 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R111 1-216-845-11 METAL CHIP 100K 5% 1/10W
R113 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R114 1-216-841-11 METAL CHIP 47K 5% 1/10W
R115 1-216-841-11 METAL CHIP 47K 5% 1/10W
R116 1-216-841-11 METAL CHIP 47K 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-227-537-11 RES, VAR, CARBON 20K/20K (VOLw)
< SWITCH >
S101 1-554-843-11 SWITCH, SLIDE (POWER)
******************************************************
* A-3347-797-A MAIN BOARD, COMPLETE
*******************
3-247-036-01 HOLDER (ANT)
3-309-597-31 SCREW (1.4), TAPPING,PRECISION
< CAPACITOR >
C1 1-162-914-11 CERAMIC CHIP 9PF 0.50PF 50V
C2 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C3 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C4 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C5 1-124-259-11 ELECT 4.7uF 20% 16V
C6 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C7 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C8 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C9 1-115-156-11 CERAMIC CHIP 1uF 10V
C10 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C11 1-136-683-11 FILM 0.0056uF 5% 100V
C12 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C13 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C14 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C15 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C16 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
C17 1-115-156-11 CERAMIC CHIP 1uF 10V
C18 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C19 1-162-945-11 CERAMIC CHIP 22PF 5% 50V
C20 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C21 1-124-584-00 ELECT 100uF 20% 10V
C22 1-115-156-11 CERAMIC CHIP 1uF 10V
C23 1-124-257-00 ELECT 2.2uF 20% 50V
C24 1-124-259-11 ELECT 4.7uF 20% 16V
C25 1-115-156-11 CERAMIC CHIP 1uF 10V
C26 1-115-156-11 CERAMIC CHIP 1uF 10V
C27 1-126-160-11 ELECT 1uF 20% 50V
C28 1-115-156-11 CERAMIC CHIP 1uF 10V
C29 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C30 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C32 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C33 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
MAIN
When indicating parts by reference
number, please include the board.
AUDIO
To Next Page
