– 20 –
IC202 8-759-472-77 IC S-80810ANNP-E70-T2
IC301 8-759-650-20 IC uPD17015GS-556-GJG
IC302 8-759-650-21 IC S-8323A25MC-ELF-T2
< COIL >
L303 1-419-311-21 INDUCTOR 100uH
L304 1-410-393-11 INDUCTOR CHIP 100uH
< TRANSISTOR >
Q301 8-729-402-13 TRANSISTOR XN1501
Q304 8-729-037-92 TRANSISTOR 2SD2216J-R(TX).SO
Q305 8-729-037-92 TRANSISTOR 2SD2216J-R(TX).SO
Q306 8-729-821-12 TRANSISTOR 2SB815B6B7.TB
Q307 8-729-037-71 TRANSISTOR UN9210J-(TX).SO
Q308 8-729-037-92 TRANSISTOR 2SD2216J-R(TX).SO
Q310 8-729-425-50 TRANSISTOR 2SB1462-Q
< RESISTOR >
R201 1-216-845-11 METAL CHIP 100K 5% 1/16W
R202 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R203 1-216-857-11 METAL CHIP 1M 5% 1/16W
R204 1-216-857-11 METAL CHIP 1M 5% 1/16W
R205 1-216-837-11 METAL CHIP 22K 5% 1/16W
R206 1-216-797-11 METAL CHIP 10 5% 1/16W
R301 1-216-797-11 METAL CHIP 10 5% 1/16W
R302 1-216-845-11 METAL CHIP 100K 5% 1/16W
R303 1-216-821-11 METAL CHIP 1K 5% 1/16W
R304 1-216-841-11 METAL CHIP 47K 5% 1/16W
R305 1-216-833-91 RES,CHIP 10K 5% 1/16W
R306 1-216-845-11 METAL CHIP 100K 5% 1/16W
R307 1-216-833-91 RES,CHIP 10K 5% 1/16W
R308 1-216-833-91 RES,CHIP 10K 5% 1/16W
R309 1-216-845-11 METAL CHIP 100K 5% 1/16W
R310 1-216-821-11 METAL CHIP 1K 5% 1/16W
R311 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R312 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R313 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R316 1-216-857-11 METAL CHIP 1M 5% 1/16W
R317 1-216-857-11 METAL CHIP 1M 5% 1/16W
R318 1-216-845-11 METAL CHIP 100K 5% 1/16W
R319 1-216-821-11 METAL CHIP 1K 5% 1/16W
R320 1-216-821-11 METAL CHIP 1K 5% 1/16W
R321 1-216-821-11 METAL CHIP 1K 5% 1/16W
R330 1-216-853-11 METAL CHIP 470K 5% 1/16W
R331 1-216-853-11 METAL CHIP 470K 5% 1/16W
R332 1-216-853-11 METAL CHIP 470K 5% 1/16W
R333 1-216-853-11 METAL CHIP 470K 5% 1/16W
R334 1-216-857-11 METAL CHIP 1M 5% 1/16W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< SWITCH >
S201 1-692-088-11 SWITCH, TACTILE (HOLD)
S202 1-692-088-11 SWITCH, TACTILE (POWER (AUTO OFF))
S203 1-692-088-11 SWITCH, TACTILE (MODE)
S205 1-475-240-12 ENCODER, ROTARY (JOG)
< TRANSFORMER >
T301 1-449-021-21 COIL, DC/DC CONVERTER
< VIBRATOR >
X201 1-767-388-11 VIBRATOR, CRYSTAL (75kHz)
**************************************************************
MISCELLANEOUS
*************
5 1-676-005-11 FLEXIBLE BOARD(B-B)
23 1-676-004-11 FLEXIBLE BOARD(B-E)
BATT2 1-528-412-11 BATTERY, PAS SECONDARY
LCD201 1-803-816-11 DISPLAY PANEL, LIQUID CRYSTAL
S205 1-475-240-12 ENCODER, ROTARY (JOG)
**************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-867-758-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
SPANISH, PORTUGUESE, CHINESE)
3-867-758-21 MANUAL, INSTRUCTION (GERMAN, DUTCH,
SWEDISH, ITALIAN, FINNISH)(AEP)
8-953-187-90 HEADPHONE MDR-ED136
SRF-M55
9-927-177-11
Sony Corporation
Personal Audio Company
99I0261-1
Printed in Japan © 1999.9
Published by General Engineering Dept.
MICROCOMPUTER
