– 4 –
2-3. LCD201
2-4. MICROCOMPUTER BOARD
1
Claws
2
Cabinet ASSY, fron
t
LCD201
1
Screws (1.4)
3
5
Cabinet ASSY, rear
4
Claw
4
Claws
2
Claws
Microcomputer board
Cover, side
