5
Operating Multiple Cameras Using the IP Remote Controller
What you can do with this system
You can operate up to 7 cameras with daisy chain connection using the IP remote controller (not supplied).
System Configuration
• Only RS-232 connection is available for VISCA CONTROL.
• You need to match the communication speed between the camera and the IP remote controller.
• You cannot use the RS-232 connections when using the LAN connection.
Notes
,
HD video monitor, VTR etc.
Video signal
Remote control (VISCA) signal
Signal flow
IP Remote Controller (not supplied)
Video switcher
To Next Page
