Unit : mm
Mounting on the EIA Standard 19-inch Rack
When mounting on top of another unit, remove the feet at the
base of the unit. (These can be removed easily by pulling out
the pins at the center of the feet with a pair of tweezers,
screwdriver, etc.)
When the rack-mount fixtures are not required, remove the
screws on the side, and remove the fixtures.
DIMENSIONS
WARNING
DIMENSIONS
350
81 320 81
482
2626 430
30
44
49.5
28345 22
