190
Menu List
Appendix
Other Items (Nos. T01 to ...)
a) Supported only on units with serial numbers 15001 or higher (excluding
SRW-5000 serial numbers 90000 to 99999, and SRW-5500 serial numbers
30000 to 39999).
A10 9-Pin TC sense
select
[LINE]
FC
Specifies whether or not the time code information of FC
output signal is returned when time code sense command
is input through the 9-pin connector.
LINE: Time code information of main output signal is
returned. In pulldown conversion mode, 24-frame/sec
time code information is returned.
FC: Time code information of FC output signal is returned.
In pulldown conversion mode, 30-frame/sec time code
is returned.
Notes
• Pulldown output signal and 30-frame/sec time code are
synchronized only when this unit is set to PLAY LOCK
mode. To synchronize the signals, set item A05 “PD EXT
SD REF LOCK MODE” to “lock2”.
• When editing pulldown output signals with a VTR
operating in 30F mode, it may not be possible to achieve
sync within 5 seconds. If this occurs, set the preroll time
to 7 seconds.
Also, normal operation is not possible with devices
engaged in player sync.
A20 Black Clip for 444 to
422 Conversion
[on]
off
When a 4:4:4 signal is converted to a 4:2:2 signal, this item
specifies whether the signal that goes below the black level
(040H) is suppressed or not.
on: Signals that drop below the black level are suppressed.
off: Signals that drop below the black level are not suppressed.
Item number Item Setting Function
T01 AUTO REPEAT
MODE
[off]
on
Selects the repeating operation of PREVIEW in automatic
editing.
off: PREVIEW in automatic editing is not repeated.
on: PREVIEW in automatic editing is repeated. To stop,
press the STOP button.
T02 INTERNAL VIDEO
SIGNAL
GENERATOR (HD)
[off]
COLOR BARS(100%)
COLOR BARS(75%)
SMPTE COLOR BARS
a)
ARIB COLOR BARS
a)
MULTI BURST 1
MULTI BURST 2
10 STEPS
PULSE & BAR
RAMP
BLACK
Selects the test signal output by the signal generator built
into the VTR.
off: The test signal is not generated, and the VTR operates
normally.
all other settings: The test signal is output from the VTR. At
this time it is also possible to record the signal.
T04 INTERNAL AUDIO
SIGNAL
GENERATOR
[off]
silence
1 kHz sine
Selects the operation of audio test signal output.
off: The audio test signal is not output.
silence: Muted signal.
1 kHz sine: 1 kHz (In this case, a 1 kHz -20 dB FS sine
wave is supplied to all audio inputs.)
Notes
• When “silence” or “1 kHz sine” is selected, the AUDIO IN
and AUDIO MONITOR L/R buttons light up.
• When the unit is operated in the 23.98 PsF or 24 PsF mode
with “1 kHz sine” selected, the output signal is 960 Hz.
Item number Item Setting Function
