Sony SS-CM90 - Page 85

84
HCD-M90
4.2 Vp-p
20.8 µs
700 mVp-
p
H
700 mVp-
p
H
ed IC701 0 (OUTC1) (Color Bar (NTSC))
ed IC701 0 (OUTC1) (Color Bar (PAL))
–DAC Board –
ra IC302 8 (IIS-IN-BCK)
rs IC302 9 (IIS-IN-WS)
5.6 Vp-
p
326 ns
13.6 Vp-
p
18.4 µs
67.2 Vp-
p
18.4 µs
ts Q401 (Collector) (REC Mode)
– TC Board –
ta T401 (REC Mode)
ys IC326 qh (RCLK) (Tuner Mode)
(AEP, UK models)
– MAIN Board –
ya IC326 qd (X1) (Tuner Mode)
(AEP, UK models)
4.4 Vp-p
850 µs
2.8 Vp-
p
231 ns
57.6 Vp-
p
18.4 µs
td T101, 201 (REC Mode)
3.2 Vp-p
30.5 µs
– CONTROL Board –
ua IC306 qa (XCOUT)
us IC306 qd (XOUT)
1.7 Vp-
p
63 ns
