Sony SS-CPX22 - Page 3

HCD-CPX22/NXM3
US Model
HCD-CPX22
AEP Model
HCD-CPX22/NXM3
UK Model
E Model
HCD-CPX22
SERVICE MANUAL
HCD-CPX22
MICRO Hi-Fi COMPONENT SYSTEM
HCD-NXM3
MiNi Hi-Fi COMPONENT SYSTEM
Sony Corporation
Audio Business Group
Published by Sony Techno Create Corporation
9-877-828-03
2007K02-1
© 2007.11
SPECIFICATIONS
Ver. 1.2 2007.11
– Continued on next page –
• HCD-CPX22 is the Amplifier, CD player,
tape deck and tuner section in CMT-CPX22.
• HCD-NXM3 is the Amplifier, CD player,
tape deck and tuner section in MHC-NXM3.
Model Name Using Similar Mechanism NEW
CD CD Mechanism Type CDM81B-F1BD81A
Section Base Unit Name BU-F1BD81A
Optical Pick-up Name KSM-215DCP/C2NP
TAPE
Model Name Using Similar Mechanism NEW
Section
Amplifier section
For the U.S.A. model
AUDIO POWER SPECIFICATIONS
HCD-CPX22
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
With 4-ohm loads, both channels driven, from 120 – 10,000 Hz;
rated 100 watts per channel minimum RMS power, with no more
than 10% total harmonic distortion from 250 milliwatts to rated
output.
Other models:
The following measured at AC 120 – 127/220 – 240 V, 50/60 Hz
(Saudi Arabian model only)
The following measured at AC 230 V, 50/60 Hz (European and
Russian models only)
The following measured at AC 120/220 – 240 V, 50/60 Hz (except
for European, Russian and Saudi Arabian models)
DIN power output (rated): 75 + 75 watts (4 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
100 + 100 watts
(4 ohms at 1 kHz, 10% THD)
Inputs
VIDEO/MD IN (phono jacks): Sensitivity 250/450 mV, impedance
47 kilohms
Outputs
DIGITAL (OPTICAL) OUT: Optical Wavelength: 660 nm
PHONES (mini jack): accepts headphones with an
impedance of 8 ohms or more
Photo : HCD-CPX22
SPEAKER: Use only the supplied speakers
SS-CPX22
(HCD-CPX22)
SS-NXM3
(HCD-NXM3)
CD player section
System Compact disc and digital audio system
Laser Semiconductor laser
(λ=770 – 810 nm)
Emission duration: continuous
Frequency response 2 Hz – 20 kHz (±0.5 dB)
Tape deck section
Recording system 4-track 2-channel stereo
Frequency response 50 – 13,000 Hz (±3 dB), using Sony
TYPE I cassettes
