62
HCD-CPX22/NXM3
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< COIL >
L1021 1-410-671-31 INDUCTOR 47uH
< TRANSISTOR >
Q1021 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1022 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1023 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1024 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q1026 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1020 1-216-809-11 METAL CHIP 100 5% 1/10W
R1021 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1022 1-216-809-11 METAL CHIP 100 5% 1/10W
R1023 1-216-809-11 METAL CHIP 100 5% 1/10W
R1024 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1025 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1026 1-216-813-11 METAL CHIP 220 5% 1/10W
R1027 1-216-815-11 METAL CHIP 330 5% 1/10W
R1028 1-216-817-11 METAL CHIP 470 5% 1/10W
R1029 1-216-819-11 METAL CHIP 680 5% 1/10W
R1030 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1031 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1032 1-216-864-11 SHORT CHIP 0
R1033 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1034 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1035 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1036 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1037 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1038 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1039 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1040 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1041 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1042 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1043 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1045 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1046 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1051 1-216-809-11 METAL CHIP 100 5% 1/10W
R1052 1-216-809-11 METAL CHIP 100 5% 1/10W
R1100 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1102 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S1021 1-762-875-21 SWITCH, KEYBOARD (CD)
S1022 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S1023 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S1024 1-762-875-21 SWITCH, KEYBOARD (VIDEO(MD))
S1025 1-762-875-21 SWITCH, KEYBOARD (DIMMER)
S1026 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S1027 1-762-875-21 SWITCH, KEYBOARD (z /START)
S1028 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S1029 1-762-875-21 SWITCH, KEYBOARD (n N)
S1030 1-762-875-21 SWITCH, KEYBOARD (CD Z)
S1031 1-762-875-21 SWITCH, KEYBOARD (X)
S1032 1-762-875-21 SWITCH, KEYBOARD (B> TUNING +)
S1033 1-762-875-21 SWITCH, KEYBOARD (.b TUNING -)
S1034 1-762-875-21 SWITCH, KEYBOARD (ALBUM +)
S1035 1-762-875-21 SWITCH, KEYBOARD (ALBUM -)
S1036 1-762-875-21 SWITCH, KEYBOARD (x)
< TRANSFORMER >
T801 1-443-389-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
A-4750-232-A RELAY BOARD, COMPLETE
*********************
< CAPACITOR >
C701 1-126-786-11 ELECT 47uF 20% 16V
C702 1-126-791-11 ELECT 10uF 20% 35V
C761 1-162-306-11 CERAMIC 0.01uF 20% 16V
C762 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN701 1-779-558-21 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-4.7C
D711 8-719-982-10 DIODE MTZJ-4.3A
< IC >
IC701 8-759-598-69 IC BA6956AN
IC711 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q751 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-415-11 CARBON 680 5% 1/4W
R712 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-806-11 CARBON 91 5% 1/4W
R752 1-249-429-11 CARBON 10K 5% 1/4W
R753 1-249-429-11 CARBON 10K 5% 1/4W
R754 1-249-430-11 CARBON 12K 5% 1/4W
R755 1-249-429-11 CARBON 10K 5% 1/4W
************************************************************
SENSOR BOARD
************
< IC >
IC751 8-759-989-76 IC RPR-359F
************************************************************
A-4750-863-A S-MASTER BOARD, COMPLETE
**********************
< CAPACITOR >
C700 1-104-658-91 ELECT 100uF 20% 10V
C701 1-126-960-11 ELECT 1uF 20% 50V
RELAYPANEL SENSOR S-MASTER
To Next Page
