13
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
SECTION 6
ELECTRICAL PARTS LIST
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC SW
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
DISPLAY
* 1-668-814-11 AC SW BOARD
***********
< CAPACITOR >
0 C951 1-113-915-11 CERAMIC 0.001uF 20% 250V
< SWITCH >
0 S901 1-572-267-51 SWITCH, PUSH (AC POWER)(1 KEY)(!)
**************************************************************
* A-4407-375-A DISPLAY BOARD, COMPLETE
***********************
* 4-921-941-01 CUSHION (FL)
* 4-945-292-01 HOLDER, INDICATION TUBE
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-162-306-11 CERAMIC 0.01uF 20% 16V
C703 1-162-209-31 CERAMIC 27PF 5% 50V
C704 1-162-209-31 CERAMIC 27PF 5% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
C706 1-164-159-21 CERAMIC 0.1uF 50V
C707 1-126-947-11 ELECT 47uF 20% 35V
C708 1-162-306-11 CERAMIC 0.01uF 20% 16V
C709 1-162-306-11 CERAMIC 0.01uF 20% 16V
C710 1-162-306-11 CERAMIC 0.01uF 20% 16V
C711 1-126-964-11 ELECT 10uF 20% 50V
C712 1-104-905-11 CAPACITOR 0.22F 5.5V
C713 1-162-306-11 CERAMIC 0.01uF 20% 16V
C714 1-126-959-11 ELECT 0.47uF 20% 50V
C717 1-162-286-21 CERAMIC 220PF 10% 50V
< DIODE >
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-991-33 DIODE 1SS133T-77
D703 8-719-991-33 DIODE 1SS133T-77
D705 8-719-991-33 DIODE 1SS133T-77
D707 8-719-991-33 DIODE 1SS133T-77
< FLUORESCENT INDICATOR >
FL701 1-517-177-21 INDICATOR TUBE, FLUORESCENT
< IC >
IC701 8-759-495-96 IC uPD780205GF-040-3BA
IC702 8-749-014-66 IC NJL64H400A
< TRANSISTOR >
Q701 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R701 1-249-437-11 CARBON 47K 5% 1/4W
R703 1-249-429-11 CARBON 10K 5% 1/4W
R704 1-249-419-11 CARBON 1.5K 5% 1/4W F
R705 1-249-419-11 CARBON 1.5K 5% 1/4W F
R707 1-249-441-11 CARBON 100K 5% 1/4W
R708 1-249-441-11 CARBON 100K 5% 1/4W
R709 1-247-807-31 CARBON 100 5% 1/4W
R710 1-249-406-11 CARBON 120 5% 1/4W F
R711 1-249-406-11 CARBON 120 5% 1/4W F
R712 1-249-407-11 CARBON 150 5% 1/4W F
R713 1-249-408-11 CARBON 180 5% 1/4W F
R714 1-247-815-91 CARBON 220 5% 1/4W
R715 1-249-410-11 CARBON 270 5% 1/4W F
R716 1-249-411-11 CARBON 330 5% 1/4W
R717 1-249-413-11 CARBON 470 5% 1/4W F
R718 1-249-414-11 CARBON 560 5% 1/4W F
R719 1-249-416-11 CARBON 820 5% 1/4W F
R720 1-249-418-11 CARBON 1.2K 5% 1/4W F
R721 1-249-421-11 CARBON 2.2K 5% 1/4W F
R722 1-249-424-11 CARBON 3.9K 5% 1/4W F
R724 1-247-807-31 CARBON 100 5% 1/4W
R725 1-249-406-11 CARBON 120 5% 1/4W F
R726 1-249-406-11 CARBON 120 5% 1/4W F
R727 1-249-407-11 CARBON 150 5% 1/4W F
R728 1-249-408-11 CARBON 180 5% 1/4W F
R729 1-247-815-91 CARBON 220 5% 1/4W
R730 1-249-410-11 CARBON 270 5% 1/4W F
R731 1-249-411-11 CARBON 330 5% 1/4W
R732 1-249-413-11 CARBON 470 5% 1/4W F
0 R733 1-249-414-11 CARBON 560 5% 1/4W F
R734 1-249-416-11 CARBON 820 5% 1/4W F
R735 1-249-418-11 CARBON 1.2K 5% 1/4W F
R736 1-247-807-31 CARBON 100 5% 1/4W
R738 1-249-401-11 CARBON 47 5% 1/4W F
R739 1-249-417-11 CARBON 1K 5% 1/4W F
R740 1-247-863-91 CARBON 22K 5% 1/4W
R741 1-247-895-91 CARBON 470K 5% 1/4W
R742 1-249-413-11 CARBON 470 5% 1/4W F
R743 1-249-413-11 CARBON 470 5% 1/4W F
R744 1-249-413-11 CARBON 470 5% 1/4W F
R745 1-249-413-11 CARBON 470 5% 1/4W F
R746 1-249-413-11 CARBON 470 5% 1/4W F
