Sony ST-SE520 - Test Mode: Circuit Check; Circuit Check Mode Operation

3
SECTION 2
TEST MODE
1. Circuit Check Mode
Set to the reception frequency that the circuit can STEREO RDS stations. (Set the input level to above 70 dB.)
This enables circuit check to be performed in any of the reception modes-FM, AM (MW, LW). Set to a desired band before setting the test
mode.
1. Turn OFF the power.
2. While pressing 4 and AUTO-BETICAL SELECT together, turn ON ! .
• The items in the following table will be checked automatically in order every 2 seconds.
FM RDS
Display Items
Tuned
IF Frq
Sig Level
Stereo
RDS Signal
AST signal =LOW
IF COUNT OK
SI LEVELh70dB
ST signal=LOW
RDS DATA OK
DISPLAY
OK or NG
OK or NG
OK or NG
OK or NG
OK or NG
AM (MW, LW)
OK or NG
OK or NG
NG
IC201 NG, RV201 adjustments
TB101, IC201 NG
TB101 NG
TB101 NG
IC802 NG
