14
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C732 1-126-925-11 ELECT 470uF 20% 10V
C733 1-104-664-11 ELECT 47uF 20% 16V
C734 1-104-664-11 ELECT 47uF 20% 16V
C735 1-164-159-11 CERAMIC 0.1uF 50V
C736 1-164-159-11 CERAMIC 0.1uF 50V
C737 1-164-159-11 CERAMIC 0.1uF 50V
C741 1-162-282-31 CERAMIC 100PF 10% 50V
C742 1-162-282-31 CERAMIC 100PF 10% 50V
C743 1-162-282-31 CERAMIC 100PF 10% 50V
C761 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN201 1-569-624-11 SOCKET, CONNECTOR 17P
CN203 1-793-351-21 SOCKET, CONNECTOR 19P
CN205 1-794-498-11 SOCKET, CONNECTOR 20P
* CN208 1-568-954-11 PIN, CONNECTOR 5P
CN211 1-784-776-11 CONNECTOR, FFC 15P (AEP,UK,AED)
CN211 1-784-774-11 CONNECTOR, FFC 13P (HK,MY,SP,KR)
CN212 1-568-828-11 CONNECTOR, FFC 9P
CN701 1-568-951-11 PIN, CONNECTOR 2P
* CN702 1-564-512-11 PLUG, CONNECTOR 9P
< DIODE >
D201 8-719-911-19 DIODE 1SS133T-72
D282 8-719-911-19 DIODE 1SS133T-72
D283 8-719-911-19 DIODE 1SS133T-72
D291 8-719-921-80 DIODE MTZJ-T-72-11B
D301 8-719-947-48 DIODE MTZJ-T-72-11A
D701 8-719-024-99 DIODE 11ES2-NTA2B
D702 8-719-024-99 DIODE 11ES2-NTA2B
D731 8-719-911-19 DIODE 1SS133T-72
D733 8-719-911-19 DIODE 1SS133T-72
< IC >
IC202 8-759-000-48 IC MC14052BCP
IC231 8-759-705-58 IC NJM4558D-D
IC281 8-759-373-82 IC TA7807SB
IC282 8-759-373-94 IC TA79007SB
IC283 8-759-373-79 IC TA7805SB
IC401 8-759-669-03 IC LC75342
IC701 8-759-681-71 IC M30620MCA-A67FP
IC702 8-759-635-63 IC M51943BSL-TP
< TRANSISTOR >
Q201 8-729-422-57 TRANSISTOR BN1A4M-TP
Q221 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q271 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q281 8-729-040-20 TRANSISTOR RT1P137L-TP
Q282 8-729-900-80 TRANSISTOR BA1A4M-TP
Q291 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q301 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q701 8-729-049-80 TRANSISTOR RTIN137S-TP
Q702 8-729-422-57 TRANSISTOR BN1A4M-TP
Q704 8-729-422-57 TRANSISTOR BN1A4M-TP
Q705 8-729-422-57 TRANSISTOR BN1A4M-TP
Q706 8-729-049-80 TRANSISTOR RTIN137S-TP
Q731 8-729-620-05 TRANSISTOR 2SC2603TP-EF
< RESISTOR >
R201 1-247-887-00 CARBON 220K 5% 1/4W
R211 1-249-425-11 CARBON 4.7K 5% 1/4W F
R212 1-249-429-11 CARBON 10K 5% 1/4W
R213 1-249-418-11 CARBON 1.2K 5% 1/4W F
R214 1-249-429-11 CARBON 10K 5% 1/4W
R215 1-249-421-11 CARBON 2.2K 5% 1/4W F
R216 1-249-429-11 CARBON 10K 5% 1/4W
R217 1-249-417-11 CARBON 1K 5% 1/4W F
R218 1-247-843-11 CARBON 3.3K 5% 1/4W
R219 1-249-393-11 CARBON 10 5% 1/4W F
R221 1-249-421-11 CARBON 2.2K 5% 1/4W F
R222 1-249-429-11 CARBON 10K 5% 1/4W
R223 1-249-429-11 CARBON 10K 5% 1/4W
R224 1-249-413-11 CARBON 470 5% 1/4W F
R225 1-249-441-11 CARBON 100K 5% 1/4W
R226 1-249-421-11 CARBON 2.2K 5% 1/4W F
R227 1-249-417-11 CARBON 1K 5% 1/4W F
R230 1-247-836-11 CARBON 1.6K 5% 1/4W
R231 1-249-437-11 CARBON 47K 5% 1/4W
R232 1-249-437-11 CARBON 47K 5% 1/4W
R261 1-249-425-11 CARBON 4.7K 5% 1/4W F
R262 1-249-429-11 CARBON 10K 5% 1/4W
R263 1-249-418-11 CARBON 1.2K 5% 1/4W F
R264 1-249-429-11 CARBON 10K 5% 1/4W
R265 1-249-421-11 CARBON 2.2K 5% 1/4W F
R266 1-249-429-11 CARBON 10K 5% 1/4W
R267 1-249-417-11 CARBON 1K 5% 1/4W F
R268 1-247-843-11 CARBON 3.3K 5% 1/4W
R269 1-249-393-11 CARBON 10 5% 1/4W F
R271 1-249-421-11 CARBON 2.2K 5% 1/4W F
R272 1-249-429-11 CARBON 10K 5% 1/4W
R273 1-249-429-11 CARBON 10K 5% 1/4W
R274 1-249-413-11 CARBON 470 5% 1/4W F
R275 1-249-441-11 CARBON 100K 5% 1/4W
R276 1-249-421-11 CARBON 2.2K 5% 1/4W F
R277 1-249-417-11 CARBON 1K 5% 1/4W F
R280 1-247-836-11 CARBON 1.6K 5% 1/4W
R291 1-249-417-11 CARBON 1K 5% 1/4W F
R292 1-249-417-11 CARBON 1K 5% 1/4W F
R301 1-247-843-11 CARBON 3.3K 5% 1/4W F
R401 1-247-807-31 CARBON 100 5% 1/4W
R402 1-247-807-31 CARBON 100 5% 1/4W
R403 1-247-807-31 CARBON 100 5% 1/4W
R702 1-247-891-00 CARBON 330K 5% 1/4W
R703 1-249-425-11 CARBON 4.7K 5% 1/4W F
R704 1-249-425-11 CARBON 4.7K 5% 1/4W F
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-249-429-11 CARBON 10K 5% 1/4W
R707 1-249-435-11 CARBON 33K 5% 1/4W
R708 1-249-435-11 CARBON 33K 5% 1/4W
R709 1-249-435-11 CARBON 33K 5% 1/4W
R710 1-249-435-11 CARBON 33K 5% 1/4W
R711 1-249-429-11 CARBON 10K 5% 1/4W
R712 1-249-429-11 CARBON 10K 5% 1/4W
R713 1-249-416-11 CARBON 820 5% 1/4W F
(AEP,UK,AED)
R713 1-249-426-11 CARBON 5.6K 5% 1/4W
(HK,MY,SP,KR)
R714 1-249-412-11 CARBON 390 5% 1/4W F
(HK,MY,SP,KR)
R714 1-249-426-11 CARBON 5.6K 5% 1/4W
(AEP,UK,AED)
R715 1-249-429-11 CARBON 10K 5% 1/4W
R716 1-249-429-11 CARBON 10K 5% 1/4W
MAIN
