15
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R717 1-249-429-11 CARBON 10K 5% 1/4W
R718 1-249-429-11 CARBON 10K 5% 1/4W
R719 1-247-807-31 CARBON 100 5% 1/4W
R720 1-249-429-11 CARBON 10K 5% 1/4W
R721 1-249-429-11 CARBON 10K 5% 1/4W
R722 1-249-417-11 CARBON 1K 5% 1/4W F
R723 1-249-417-11 CARBON 1K 5% 1/4W F
R724 1-249-429-11 CARBON 10K 5% 1/4W
R725 1-249-441-11 CARBON 100K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-417-11 CARBON 1K 5% 1/4W F
R733 1-249-425-11 CARBON 4.7K 5% 1/4W F
R734 1-249-437-11 CARBON 47K 5% 1/4W
R735 1-249-437-11 CARBON 47K 5% 1/4W
R736 1-249-429-11 CARBON 10K 5% 1/4W
R737 1-249-429-11 CARBON 10K 5% 1/4W
R741 1-247-807-31 CARBON 100 5% 1/4W
R742 1-247-807-31 CARBON 100 5% 1/4W
R743 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-807-31 CARBON 100 5% 1/4W
R754 1-247-807-31 CARBON 100 5% 1/4W
R755 1-247-807-31 CARBON 100 5% 1/4W
R757 1-247-807-31 CARBON 100 5% 1/4W
R758 1-247-807-31 CARBON 100 5% 1/4W
R759 1-247-807-31 CARBON 100 5% 1/4W
R760 1-247-807-31 CARBON 100 5% 1/4W
R761 1-247-807-31 CARBON 100 5% 1/4W
R762 1-247-807-31 CARBON 100 5% 1/4W
R764 1-247-807-31 CARBON 100 5% 1/4W
R765 1-247-807-31 CARBON 100 5% 1/4W
R766 1-247-807-31 CARBON 100 5% 1/4W
R767 1-247-807-31 CARBON 100 5% 1/4W
R768 1-247-807-31 CARBON 100 5% 1/4W
R769 1-247-807-31 CARBON 100 5% 1/4W
R770 1-247-807-31 CARBON 100 5% 1/4W
R771 1-247-807-31 CARBON 100 5% 1/4W
R772 1-247-807-31 CARBON 100 5% 1/4W
R773 1-247-807-31 CARBON 100 5% 1/4W
R774 1-247-807-31 CARBON 100 5% 1/4W
R775 1-247-807-31 CARBON 100 5% 1/4W
R776 1-247-807-31 CARBON 100 5% 1/4W
R777 1-247-807-31 CARBON 100 5% 1/4W
R778 1-249-401-11 CARBON 47 5% 1/4W F
R779 1-249-401-11 CARBON 47 5% 1/4W F
< VIBRATOR >
X701 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
X702 1-567-098-41 VIBRATOR, CRYSTAL (32.768KHz)
**************************************************************
1-678-671-11 PANEL BOARD
**********
< CAPACITOR >
C901 1-124-584-00 ELECT 100uF 20% 10V
C902 1-161-494-00 CERAMIC 0.022uF 25V
C903 1-161-494-00 CERAMIC 0.022uF 25V
C904 1-162-290-31 CERAMIC 470PF 10% 50V
C905 1-162-290-31 CERAMIC 470PF 10% 50V
C906 1-162-290-31 CERAMIC 470PF 10% 50V
< CONNECTOR >
CN901 1-784-731-11 CONNECTOR, FFC 9P
CN902 1-580-471-11 SOCKET, CONNECTOR 6P
< IC >
IC901 8-749-016-97 IC NJL62H400A (REMOTE SENSOR)
< RESISTOR >
R901 1-247-807-31 CARBON 100 5% 1/4W
R902 1-247-807-31 CARBON 100 5% 1/4W
R903 1-247-807-31 CARBON 100 5% 1/4W
R904 1-247-854-11 CARBON 9.1K 5% 1/4W
R905 1-249-417-11 CARBON 1K 5% 1/4W F
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-249-401-11 CARBON 47 5% 1/4W F
R921 1-249-425-11 CARBON 4.7K 5% 1/4W F
R922 1-249-427-11 CARBON 6.8K 5% 1/4W F
R923 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S910 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S920 1-771-410-21 SWITCH, TACTILE (TUNING MODE)
S921 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S922 1-771-410-21 SWITCH, TACTILE (-TUNING)
S923 1-771-410-21 SWITCH, TACTILE (+TUNING)
**************************************************************
1-678-673-11 PIN JACK BOARD
*************
< CAPACITOR >
C226 1-162-292-31 CERAMIC 680PF 10% 50V
C227 1-162-292-31 CERAMIC 680PF 10% 50V
C276 1-162-292-31 CERAMIC 680PF 10% 50V
C277 1-162-292-31 CERAMIC 680PF 10% 50V
C295 1-164-159-11 CERAMIC 0.1uF 50V
< JACK >
J210 1-695-188-31 JACK, PIN 4P (AUX IN/OUT)
**************************************************************
MISCELLANEOUS
*************
1 1-769-916-11 WIRE (FLAT TYPE) (9 CORE)
14 1-769-970-11 WIRE (FLAT TYPE) (13 CORE) (HK,MY,SP,KR)
14 1-773-002-11 WIRE (FLAT TYPE) (15 CORE) (AEP,UK,AED)
19 1-693-482-11 TUNER (FM/AM) (HK,MY,SP,KR)
19 1-693-499-11 TUNER (FM/AM) (AEP,UK,AED)
LCD101 1-804-056-11 DISPLAY PANEL, LIQUID CRYSTAL
PANEL
PIN JACK
MAIN
