Sony STR-D550Z - Rear Panel Descriptions

26
EN
1 ANTENNA (AM/FM)
2 y ground terminal
3 S-LINK CTRL A1 jack (USA and
Canadian STR-DE705 only)
4 MONITOR
5 TV/DBS
6 VIDEO 2
7 VIDEO 1
8 MIX OUT
9 FRONT SPEAKERS (A/B)
0 IMPEDANCE SELECTOR
(STR-DE705 and STR-D650Z
only)
!¡ AC power cord
!™ SWITCHED AC OUTLETs
(Outlet shape and position varies
according to destination)
!£ SURROUND SPEAKERS
(CENTER)
!¢ SURROUND SPEAKERS
(REAR)
!∞ TAPE MONITOR
!§ DAT/MD
!¶ CD
!• PHONO
1
2
345
67 8
9
0
!¡
!• !¶ !§ !∞ !™!£!¢
Rear Panel Descriptions
