Sony STR-DA3000ES - Page 123

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
123
STR-DA3000ES
AUDIO
C612 1-216-295-00 SHORT CHIP 0
C613 1-216-295-00 SHORT CHIP 0
C614 1-216-295-00 SHORT CHIP 0
C615 1-216-295-00 SHORT CHIP 0
C631 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C632 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C642 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
(US, CND)
C643 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
(US, CND)
C644 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(US, CND)
C691 1-127-728-51 ELECT 2200uF 20% 25V
(US, CND)
C691 1-135-686-51 ELECT 2200uF 25V
(EXCEPT US, CND)
C692 1-127-728-51 ELECT 2200uF 20% 25V
(US, CND)
C692 1-135-686-51 ELECT 2200uF 25V
(EXCEPT US, CND)
C693 1-127-728-51 ELECT 2200uF 20% 25V
(US, CND)
C693 1-135-686-51 ELECT 2200uF 25V
(EXCEPT US, CND)
C694 1-136-169-00 MYLAR 0.22uF 5% 50V
C695 1-136-169-00 MYLAR 0.22uF 5% 50V
C696 1-119-803-11 ELECT 470uF 20% 25V
(EXCEPT US, CND)
C696 1-127-726-91 ELECT 470uF 20% 25V
(US, CND)
C697 1-136-169-00 MYLAR 0.22uF 5% 50V
C698 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CNP603 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP604 1-784-926-11 PIN, CONNECTOR 11P
CNP605 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CNP606 1-779-978-11 PIN, CONNECTOR 3P
CNP607 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP608 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP609 1-691-765-11 PLUG (MICRO CONNECTOR) 3P (US, CND)
CNP610 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP611 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
(US, CND)
CNP612 1-784-922-11 PIN, CONNECTOR 5P (EXCEPT US, CND)
CNP613 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CNP617 1-784-038-11 CONNECTOR, BOARD TO BOARD 9P
* CNP618 1-766-600-11 CONNECTOR, BOARD TO BOARD 7P
CNP619 1-770-010-11 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D641 8-719-988-61 DIODE 1SS355TE-17 (US, CND)
< GROUND TERMINAL >
* EPT601 1-537-738-21 TERMINAL, EARTH
< IC >
IC131 8-759-832-29 IC NJM4580M-(TE2)
IC231 8-759-832-29 IC NJM4580M-(TE2)
IC301 8-759-832-29 IC NJM4580M-(TE2)
IC311 8-759-832-29 IC NJM4580M-(TE2)
IC312 8-759-832-29 IC NJM4580M-(TE2)
IC313 8-759-832-29 IC NJM4580M-(TE2)
IC321 8-759-832-29 IC NJM4580M-(TE2)
IC322 8-759-832-29 IC NJM4580M-(TE2)
IC326 8-759-835-79 IC TC9274N-016
IC327 8-759-832-29 IC NJM4580M-(TE2)
IC341 8-759-835-79 IC TC9274N-016
IC401 8-759-835-78 IC TC9274N-015
IC501 8-759-835-78 IC TC9274N-015
IC611 8-759-832-29 IC NJM4580M-(TE2)
IC612 8-759-832-29 IC NJM4580M-(TE2)
IC613 8-759-832-29 IC NJM4580M-(TE2)
IC614 8-759-832-29 IC NJM4580M-(TE2)
IC615 8-759-832-29 IC NJM4580M-(TE2)
IC616 8-759-832-29 IC NJM4580M-(TE2)
IC617 8-759-832-29 IC NJM4580M-(TE2)
IC618 8-759-832-29 IC NJM4580M-(TE2)
IC619 8-759-832-29 IC NJM4580M-(TE2)
IC620 8-759-832-29 IC NJM4580M-(TE2)
IC621 8-759-832-29 IC NJM4580M-(TE2)
IC641 8-759-832-29 IC NJM4580M-(TE2) (US, CND)
IC642 6-702-387-01 IC CXD9725M (US, CND)
IC643 8-759-832-29 IC NJM4580M-(TE2) (US, CND)
IC691 8-759-231-53 IC TA7805S
IC692 8-759-238-47 IC TC74HCT7007AF(EL)
< JACK >
J601 1-695-188-31 JACK, PIN 4P (MULTI CHANNEL INPUT 2
FRONT/SURROUND)
J602 1-770-272-11 JACK, PIN 2P (MULTI CHANNEL INPUT 2
SURR BACK) (US, CND)
J602 1-770-377-31 JACK, PIN 1P (MULTI CHANNEL INPUT 2
SURR BACK) (EXCEPT US, CND)
J603 1-770-157-21 JACK, PIN 2P (MULTI CHANNEL INPUT 2
CENTER/SUB WOOFER)
J604 1-779-599-11 JACK, PIN 6P (MULTI CHANNEL INPUT 1
FRONT/SURROUND/CENTER/SUB WOOFER)
J605 1-774-411-11 JACK, PIN 6P
(PHONO IN, CD/DVD IN, MD DAT OUT)
J606 1-774-411-11 JACK, PIN 6P
(MD/DAT IN, TAPE OUT, TAPE IN)
J607 1-774-411-11 JACK, PIN 6P (TV/SAT AUDIO IN,
DVD AUDIO IN, VIDEO2 AUDIO OUT)
J608 1-774-411-11 JACK, PIN 6P (VIDEO2 AUDIO IN,
VIDEO1 AUDIO IN, VIDEO1 AUDIO OUT)
J609 1-770-272-11 JACK, PIN 2P (2ND ZONE OUT AUDIO
VARIABLE) (US, CND) (US, CND)
< RESISTOR >
JW1 1-216-295-00 SHORT CHIP 0 (EXCEPT US, CND)
< TRANSISTOR >
Q631 8-729-230-49 TRANSISTOR 2SC2712-YG (US, CND)
Q632 8-729-027-24 TRANSISTOR DTA114TKA-T146 (US, CND)
Q641 8-729-230-49 TRANSISTOR 2SC2712-YG (US, CND)
