Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
128
STR-DA3000ES
AUDIO CIS
R563 1-260-008-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R564 1-216-222-00 RES-CHIP 1K 2% 1/8W
(US, CND)
R564 1-260-008-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R585 1-216-013-00 RES-CHIP 33 5% 1/10W
R586 1-216-013-00 RES-CHIP 33 5% 1/10W
R587 1-216-295-00 SHORT CHIP 0
R588 1-216-295-00 SHORT CHIP 0
R589 1-216-295-00 SHORT CHIP 0
R591 1-208-782-11 METAL CHIP 1K 0.5% 1/10W
(US, CND)
R591 1-259-995-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R592 1-208-782-11 METAL CHIP 1K 0.5% 1/10W
(US, CND)
R592 1-259-995-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R593 1-208-782-11 METAL CHIP 1K 0.5% 1/10W
(US, CND)
R593 1-259-995-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R594 1-208-782-11 METAL CHIP 1K 0.5% 1/10W
(US, CND)
R594 1-259-995-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R631 1-216-001-00 RES-CHIP 10 5% 1/10W
(US, CND)
R632 1-216-033-00 RES-CHIP 220 5% 1/10W
(US, CND)
R633 1-216-049-11 RES-CHIP 1K 5% 1/10W
(US, CND)
R642 1-216-013-00 RES-CHIP 33 5% 1/10W
(US, CND)
R643 1-216-013-00 RES-CHIP 33 5% 1/10W
(US, CND)
R644 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
(US, CND)
R645 1-216-073-00 RES-CHIP 1K 5% 1/10W
(US, CND)
0R646 1-249-393-11 CARBON 10 5% 1/4W F
(US, CND)
R647 1-216-295-00 SHORT CHIP 0 (US, CND)
R648 1-216-295-00 SHORT CHIP 0 (US, CND)
R649 1-216-295-00 SHORT CHIP 0 (US, CND)
R681 1-260-008-11 CARBON MELF 1K 2% 1/8W
R682 1-260-008-11 CARBON MELF 1K 2% 1/8W
< RELAY >
RY641 1-755-486-11 RELAY (US, CND)
************************************************************
A-4734-119-A CIS BOARD, COMPLETE (US, CND)
*******************
< CAPACITOR/SHORT >
C801 1-126-947-11 ELECT 47uF 20% 35V
C802 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C803 1-126-961-11 ELECT 2.2uF 20% 50V
C804 1-126-947-11 ELECT 47uF 20% 35V
C805 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C831 1-126-960-11 ELECT 1uF 20% 50V
C841 1-126-960-11 ELECT 1uF 20% 50V
C851 1-126-767-11 ELECT 1000uF 20% 16V
C852 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C861 1-216-295-00 SHORT CHIP 0
C862 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C863 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C864 1-126-963-11 ELECT 4.7uF 20% 50V
C865 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C866 1-216-295-00 SHORT CHIP 0
C867 1-216-295-00 SHORT CHIP 0
C868 1-216-295-00 SHORT CHIP 0
< CONNECTOR >
CN801 1-568-826-11 CONNECTOR, FFC 7P
CN851 1-564-505-11 PLUG, CONNECTOR 2P
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-075-86 LED SID307BRTP19
(REMOTE CONTROL TRANSCEIVER)
D803 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC801 8-759-827-69 IC NJL63H400A-1
IC802 8-759-564-49 IC TC7W53FU (TE12R)
IC861 8-759-470-63 IC NJM2145M-TE2
< JACK >
J801 1-563-330-11 JACK (IR REMOTE, IR IN)
J802 1-563-330-11 JACK (IR REMOTE, IR OUT1)
J803 1-563-330-11 JACK (IR REMOTE, IR OUT2)
J831 1-563-330-11 JACK (TRIGGER OUT, 2ND ZONE)
J841 1-563-330-11 JACK (TRIGGER OUT, MAIN)
J861 1-563-330-11 JACK (CONTROL S OUT)
J862 1-563-330-11 JACK (CONTROL S IN)
< SHORT >
JW861 1-216-295-00 SHORT CHIP 0
< TRANSISTOR >
Q831 8-729-140-93 TRANSISTOR 2SB733-34
Q832 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q841 8-729-140-93 TRANSISTOR 2SB733-34
Q842 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR/THERMISTOR >
R801 1-216-073-00 RES-CHIP 1K 5% 1/10W
R802 1-216-001-00 RES-CHIP 10 5% 1/10W
R803 1-216-097-11 RES-CHIP 100K 5% 1/10W
R804 1-216-073-00 RES-CHIP 1K 5% 1/10W
R805 1-216-097-11 RES-CHIP 100K 5% 1/10W
R806 1-216-025-11 RES-CHIP 100 5% 1/10W
R807 1-216-025-11 RES-CHIP 100 5% 1/10W
R825 1-216-025-11 RES-CHIP 100 5% 1/10W
R831 1-801-726-11 THERMISTOR, POSITIVE
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
