Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
153
STR-DA3000ES
C2934 1-216-295-00 SHORT CHIP 0
C2935 1-128-858-11 ELECT 22uF 20% 50V
C2936 1-128-832-11 ELECT 220uF 20% 10V
C2937 1-137-505-11 MYLAR 220PF 5% 100V
C2938 1-128-858-11 ELECT 22uF 20% 50V
C2939 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2951 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2965 1-128-858-11 ELECT 22uF 20% 50V
C2966 1-128-832-11 ELECT 220uF 20% 10V
C2967 1-137-505-11 MYLAR 220PF 5% 100V
C2968 1-128-858-11 ELECT 22uF 20% 50V
C2969 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2972 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C2973 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C2974 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C2983 1-216-295-00 SHORT CHIP 0
C2985 1-128-858-11 ELECT 22uF 20% 50V
C2986 1-128-832-11 ELECT 220uF 20% 10V
C2987 1-137-505-11 MYLAR 220PF 5% 100V
C2988 1-128-858-11 ELECT 22uF 20% 50V
C2989 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN2902 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CN2903 1-779-977-11 PIN, CONNECTOR 6P
CN2904 1-784-929-11 PIN, CONNECTOR 14P
< DIODE >
D2801 8-719-988-61 DIODE 1SS355TE-17
D2851 8-719-988-61 DIODE 1SS355TE-17
D2901 8-719-988-61 DIODE 1SS355TE-17
D2951 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC2812 6-702-387-01 IC CXD9725M
IC2813 8-759-832-29 IC NJM4580M-(TE2)
IC2862 6-702-387-01 IC CXD9725M
IC2863 8-759-832-29 IC NJM4580M-(TE2)
IC2912 6-702-387-01 IC CXD9725M
IC2913 8-759-832-29 IC NJM4580M-(TE2)
IC2962 6-702-387-01 IC CXD9725M
IC2963 8-759-832-29 IC NJM4580M-(TE2)
< JACK >
J2815 1-817-960-11 JACK, PIN 2P
(SUB WOOFER AUDIO OUT, PREOUT CENTER)
J2875 1-793-525-21 JACK, PIN 2P (PREOUT SURROUND BACK)
J2915 1-793-525-21 JACK, PIN 2P (PREOUT SURROUND)
J2975 1-793-525-21 JACK, PIN 2P (PREOUT FRONT)
< COIL >
L2801 1-410-509-11 MICRO INDUCTOR 10uH
< TRANSISTOR >
Q2800 8-729-027-24 TRANSISTOR DTA114TKA-T146
Q2801 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2851 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2901 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2951 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R2802 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R2803 1-216-073-00 RES-CHIP 1K 5% 1/10W
0R2804 1-249-393-11 CARBON 10 5% 1/4W F
R2805 1-216-097-11 RES-CHIP 100K 5% 1/10W
R2806 1-216-295-00 SHORT CHIP 0
R2807 1-216-295-00 SHORT CHIP 0
R2808 1-216-295-00 SHORT CHIP 0
R2817 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2818 1-216-013-00 RES-CHIP 33 5% 1/10W
R2819 1-216-097-11 RES-CHIP 100K 5% 1/10W
R2820 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
R2822 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R2824 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2835 1-216-097-11 RES-CHIP 100K 5% 1/10W
R2837 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2838 1-216-013-00 RES-CHIP 33 5% 1/10W
R2839 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R2840 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
R2842 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R2844 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2852 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R2853 1-216-073-00 RES-CHIP 1K 5% 1/10W
0R2854 1-249-393-11 CARBON 10 5% 1/4W F
R2855 1-216-097-11 RES-CHIP 100K 5% 1/10W
R2856 1-216-295-00 SHORT CHIP 0
R2857 1-216-295-00 SHORT CHIP 0
R2858 1-216-295-00 SHORT CHIP 0
R2867 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2868 1-216-013-00 RES-CHIP 33 5% 1/10W
R2869 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R2870 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
R2872 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R2873 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2887 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2888 1-216-013-00 RES-CHIP 33 5% 1/10W
R2889 1-216-097-11 RES-CHIP 100K 5% 1/10W
R2890 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
R2892 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R2893 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2902 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R2903 1-216-073-00 RES-CHIP 1K 5% 1/10W
0R2904 1-249-393-11 CARBON 10 5% 1/4W F
R2905 1-216-097-11 RES-CHIP 100K 5% 1/10W
R2906 1-216-295-00 SHORT CHIP 0
R2907 1-216-295-00 SHORT CHIP 0
R2908 1-216-295-00 SHORT CHIP 0
R2917 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2918 1-216-013-00 RES-CHIP 33 5% 1/10W
R2919 1-216-097-11 RES-CHIP 100K 5% 1/10W
R2920 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
R2922 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R2923 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2937 1-208-437-41 RES-CHIP 1K 2% 1/10W
R2938 1-216-013-00 RES-CHIP 33 5% 1/10W
R2939 1-216-097-11 RES-CHIP 100K 5% 1/10W
PRE-OUT
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
