Sony STR-DA3000ES - Page 164

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
164
STR-DA3000ES
1-688-727-11 VOL BOARD
*********
< CONNECTOR >
* CN1004 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< ROTARY ENCODER >
RV1007 1-477-382-11 ENCODER, ROTARY (MASTER VOLUME)
************************************************************
MISCELLANEOUS
**************
60 1-500-249-21 BEAD, FERRITE (CASE) (AEP, TW, KR)
70 1-827-364-11 WIRE (FLAT TYPE) (23 CORE)
72 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
154 1-469-969-11 CLAMP, FERRITE (US, CND)
155 1-773-036-11 WIRE (FLAT TYPE) (17 CORE)
156 1-769-878-11 WIRE (FLAT TYPE) (7 CORE) (US, CND)
157 1-769-943-11 WIRE (FLAT TYPE) (11 CORE)
(US, CND, TW, KR)
157 1-773-007-11 WIRE (FLAT TYPE) (15 CORE) (AEP)
160 1-400-061-11 CORE, FERRITE (CLAMP FILTER) (US, CND)
204 1-500-472-11 CORE, FERRITE
* 206 1-500-169-11 CORE (FPC)
207 1-773-390-11 WIRE (FLAT TYPE) (35 CORE)
208 1-400-583-11 CORE, FERRITE
252 1-469-969-11 CLAMP, FERRITE
254 1-500-037-11 CORE, FERRITE (WITH CASE)
257 1-469-854-11 CORE, FERRITE
258 1-773-221-11 WIRE (FLAT TYPE) (25 CORE)
303 1-500-753-11 CLAMP, FERRITE (EXCEPT US, CND)
304 1-469-969-11 CLAMP, FERRITE (US, CND)
305 1-400-061-11 CORE, FERRITE (CLAMP FILTER) (US, CND)
IC904 8-759-231-53 IC TA7805S
IC905 8-759-394-36 IC BA09T
IC906 8-759-245-79 IC TA79005S
IC909 8-759-445-59 IC BA033T
IC910 8-759-231-53 IC TA7805S
Q904 6-550-625-01 TRANSISTOR 2SK1381
Q909 6-702-390-01 IC MN2488-OPY-MK
TU2051 1-693-577-21 TUNER (US, CND)
TU2051 1-693-578-21 TUNER (AEP)
TU2051 1-693-580-23 TUNER (TW, KR)
************************************************************
ACCESSORIES
************
1-400-550-11 FILTER, CLAMP
1-477-843-11 COMMANDER, STANDARD (RM-LG112)
1-478-000-11 COMMANDER, STANDARD (RM-US106)
(US, CND)
1-501-374-12 ANTENNA, LOOP (AM)
1-501-594-14 ANTENNA (FM) (AEP, TW)
0 1-551-631-22 CORD, POWER (AEP)
0 1-790-396-12 CORD, POWER (TW)
1-793-184-23 CONNECTOR (F TYPE ADAPTOR)
(US, CND, TW, KR)
0 1-823-512-12 CORD, POWER (US, CND)
0 1-824-326-11 POWER-SUPPLY CORD (KR)
3-071-119-01 COVER, BATTERY (for RM-LG112)
4-228-696-01 COVER, BATTERY (for RM-US106) (US, CND)
4-247-188-12 MANUAL, INSTRUCTION (ENGLISH)
(EXCEPT KR)
4-247-188-22 MANUAL, INSTRUCTION (FRENCH)
(CND, AEP)
4-247-188-32 MANUAL, INSTRUCTION (SPANISH) (AEP)
4-247-188-42 MANUAL, INSTRUCTION
(GERMAN, DUTCH, ITALIAN) (AEP)
4-247-188-52 MANUAL, INSTRUCTION (SWEDISH, POLISH)
(AEP)
4-247-188-61 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE, SIMPLIFIED CHINESE)
(TW)
4-247-188-71 MANUAL, INSTRUCTION (KOREAN) (KR)
4-247-232-11 MANUAL, INSTRUCTION (PORTUGUESE)(AEP)
4-247-232-21 MANUAL, INSTRUCTION (DANISH, FINNISH)
(AEP)
4-247-232-31 MANUAL, INSTRUCTION (RUSSIAN) (AEP)
4-247-232-41 MANUAL, INSTRUCTION (GREEK) (AEP)
4-247-232-51 MANUAL, INSTRUCTION (HUNGARIAN,
CZECK) (AEP)
4-247-232-61 MANUAL, INSTRUCTION (SLOVAKIAN) (AEP)
4-247-234-11 MANUAL, INSTRUCTION, INSTALL
(ENGLISH, FRENCH) (US, CND)
4-247-234-21 MANUAL, INSTRUCTION, INSTALL
(ENGLISH, FRENCH, SPANISH) (AEP, TW)
4-247-234-31 MANUAL, INSTRUCTION, INSTALL
(GERMAN, DUTCH, ITALIAN) (AEP)
4-247-234-41 MANUAL, INSTRUCTION, INSTALL
(SWEDISH, POLISH) (AEP)
4-247-234-51 MANUAL, INSTRUCTION, INSTALL
(TRADITIONAL CHINESE, KOREAN)
(TW, KR)
4-247-234-61 MANUAL, INSTRUCTION, INSTALL
(PORTUGUESE, DANISH, FINNISH, RUSSIAN)
(AEP)
4-247-234-71 MANUAL, INSTRUCTION, INSTALL
(GREEK, HUNGARIAN, CZECK, SLOVAKIAN)
(AEP)
4-247-243-61 MANUAL, INSTRUCTION
(PORTUGUESE, DANISH, FINNISH, RUSSIAN)
(AEP)
4-247-243-71 MANUAL, INSTRUCTION
(GREEK, HUNGARIAN, CZECK, SLOVAKIAN)
(AEP)
4-247-238-11 MANUAL, INSTRUCTION (RM-US106)
(ENGLISH, FRENCH) (US, CND)
4-249-323-11 MANUAL, INSTRUCTION (RM-LG112)
(ENGLISH) (EXCEPT KR)
4-249-323-21 MANUAL, INSTRUCTION (RM-LG112)
(FRENCH) (CND, AEP)
4-249-323-31 MANUAL, INSTRUCTION (RM-LG112)
(SPANISH, GERMAN, DUTCH, ITALIAN,
SWEDISH, POLISH) (AEP)
4-249-323-41 MANUAL, INSTRUCTION (RM-LG112)
(TRADITIONAL CHINESE) (TW)
4-249-323-51 MANUAL, INSTRUCTION (RM-LG112)
(KOREAN) (KR)
4-251-318-01 COVER, PROTECTION
* 4-950-766-01 LABEL, FCC DIGITAL DEVICE (US)
VOL
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
