150
US
Frequency response
3)
3)
When “2ch Analog Direct” is being used.
Inputs (Analog)
Inputs (Digital)
Outputs
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
AM tuner section
Intermediate frequency
450 kHz
Antenna (aerial) Loop antenna (aerial)
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
: 0.7 Vp-p, 75 ohms
P
R
: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
HDMI Video
Input/Output (HDMI Repeater block)
640 × 480p @ 59.94/60 Hz
720 × 480p @ 59.94/60 Hz
1280 × 720p @ 59.94/60 Hz
1920 × 1080i @ 59.94/60 Hz
1920 × 1080p @ 59.94/60 Hz
720 × 576p @ 50 Hz
1280 × 720p @ 50 Hz
1920 × 1080i @ 50 Hz
1920 × 1080p @ 50 Hz
1280 × 720p @ 29.97/30 Hz
1920 × 1080p @ 29.97/30 Hz
1280 × 720p @ 23.98/24 Hz
1920 × 1080p @ 23.98/24 Hz
HDMI Video (3D)
Input/Output (HDMI Repeater block)
1280 × 720p @ 59.94/60 Hz
Frame Packing
Side-by-Side (Half)
Over-Under (Top-and-Bottom)
1920 × 1080i @ 59.94/60 Hz
Frame Packing
Side-by-Side (Half)
Over-Under (Top-and-Bottom)
1920 × 1080p @ 59.94/60 Hz
Side-by-Side (Half)
Over-Under (Top-and-Bottom)
PHONO RIAA equalization
curve ± 1.0 dB (20 Hz –
20 kHz)
MULTI CHANNEL
INPUT, SA-CD/CD,
TAPE, MD, TV,
VIDEO 1/2, BD/DVD,
SAT/CATV, GAME
10 Hz – 100 kHz
± 3 dB
PHONO Sensitivity: 2.5 mV
Impedance: 50 kohms
S/N: 90 dB (A, 20 kHz
LPF)
MULTI CHANNEL
INPUT, SA-CD/CD,
TAPE, MD, TV,
VIDEO 1/2, BD/DVD,
SAT/CATV, GAME
Sensitivity: 150 mV
Impedance: 50 kohms
S/N: 100 dB (A,
20 kHz LPF)
IN 1 (BD/DVD), IN 2
(VIDEO 1), IN 3 (SA-
CD/CD) (Coaxial)
Impedance: 75 ohms
S/N: 96 dB (A, 20 kHz
LPF)
IN 1 (GAME), IN 2
(SAT/CATV), IN 3 (TV),
IN 4 (MD) (Optical)
S/N: 96 dB
(A, 20 kHz LPF)
TAPE (REC OUT),
VIDEO 1, ZONE 2,
ZONE 3 (AUDIO OUT)
Voltage:150 mV
Impedance: 1 kohm
FRONT L/R, CENTER,
SURROUND L/R,
SURROUND BACK L/R
,
FRONT HIGH L/R,
SUBWOOFER
Voltage: 2 V
Impedance: 1 kohm
Tuning scale Tuning range
10 kHz step 530 – 1,710 kHz
9 kHz step 531 – 1,710 kHz
