33
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
51 X-4947-124-1 FOOT ASSY (F50150S)(SILVER)
(DE445:AEP,UK,CIS/DE545:E,PX,AUS)
51 X-4947-208-1 FOOT ASSY (F50150S)(BLACK)
(DE445:US,CND,AEP,UK/DE545:CH,US,CND,AEP,UK,CIS,SE501)
51 X-4947-389-1 FOOT ASSY (F50150S)(BLACK)(DE445:CIS)
51 X-4947-547-1 FOOT ASSY (F50150S)(DE545:TW,SP,MY)
52 4-226-801-01 SUB MOLD (E5)
* 53 4-954-051-51 HOLDER, PC BOARD(DE445)
54 A-4428-423-A MAIN BOARD, COMPLETE(DE445:US)
54 A-4428-429-A MAIN BOARD, COMPLETE(DE545:US,SE501)
54 A-4428-463-A MAIN BOARD, COMPLETE(DE445:CND)
54 A-4428-465-A MAIN BOARD, COMPLETE(DE445:AEP,UK,CIS)
54 A-4428-467-A MAIN BOARD, COMPLETE(DE545:CND,E,PX)
54 A-4428-469-A MAIN BOARD, COMPLETE(DE545:AEP,UK,CIS)
54 A-4428-490-A MAIN BOARD, COMPLETE
(DE545:CH,TW,SP,MY,AUS)
55 3-905-609-01 SCREW (TRANSISTOR)
* 56 4-924-098-91 HOLDER, PC BOARD
57 A-4428-435-A STBY BOARD, COMPLETE(US,CND)
57 A-4428-478-A STBY BOARD, COMPLETE(E,PX)
57 A-4428-481-A STBY BOARD, COMPLETE(AEP,UK,CIS,SP,MY)
57 A-4428-491-A STBY BOARD, COMPLETE(AUS)
57 A-4428-497-A STBY BOARD, COMPLETE(CH)
57 A-4473-334-A STBY BOARD, COMPLETE(TW)
* 58 3-703-244-00 BUSHING (2104), CORD
0 59 1-696-847-11 CORD, POWER(AUS)
0 59 1-777-070-21 CORD, POWER(CND)
0 59 1-777-071-21 CORD, POWER(AEP,UK,CIS,SP,MY,TW,E,PX)
0 59 1-783-205-11 CORD, POWER(CH)
0 59 1-783-820-11 CORD, POWER(US)
60 4-226-802-01 BACK PANEL (E5)(DE545:US)
60 4-226-802-11 BACK PANEL (E5)(DE545:CND)
60 4-226-802-21 BACK PANEL (E5)(DE545:AUS)
60 4-226-802-31 BACK PANEL (E5)(DE545:E,PX)
60 4-226-802-41 BACK PANEL (E5)(DE545:SP,MY)
60 4-226-802-51 BACK PANEL (E5)(DE545:CH)
60 4-226-802-61 BACK PANEL (E5)(DE545:AEP,UK,CIS)
60 4-226-802-71 BACK PANEL (E5)(DE545:TW)
60 4-226-808-01 BACK PANEL (E4)(DE445:US)
60 4-226-808-11 BACK PANEL (E4)(DE445:CND)
60 4-226-808-21 BACK PANEL (E4)(DE445:AEP,UK)
60 4-226-808-31 BACK PANEL (E4)(DE445:CIS)
60 4-227-063-01 BACK PANEL (S5)(SE501)
61 4-956-370-12 BAND, PLUG FIXED(DE545:TW,AUS)
62 1-676-781-11 VIDEO BOARD
63 1-769-840-11 WIRE(FLAT TYPE) (5 CORE)(DE545,SE501)
64 1-676-782-11 S-VIDEO BOARD(DE545,SE501)
65 A-4424-456-A DIGITAL BOARD, COMPLETE(DE445)
65 A-4424-459-A DIGITAL BOARD, COMPLETE(DE545,SE501)
66 1-693-407-41 TUNER(TW,US,CND,E)
66 1-693-408-41 TUNER(CH,AEP,UK,CIS,SP,MY,AUS)
67 1-773-001-11 WIRE(FLAT TYPE) (15 CORE)
0 68 1-569-008-21 ADAPTOR, CONVERSION 2P(E,PX)
69 1-676-788-11 AC SEL BOARD(E,PX)
70 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
0 T901 1-435-306-11 TRANSFORMER, POWER(DE545:US)
0 T901 1-435-306-21 TRANSFORMER, POWER(SE501)
0 T901 1-435-307-11 TRANSFORMER, POWER(DE545:CND)
0 T901 1-435-308-11 TRANSFORMER, POWER(DE545:AUS)
0 T901 1-435-309-11 TRANSFORMER, POWER
(DE545:CH,AEP,UK,CIS,SP,MY)
0 T901 1-435-310-11 TRANSFORMER, POWER(DE545:E,PX)
0 T901 1-435-312-11 TRANSFORMER, POWER(DE445:CND)
0 T901 1-435-313-11 TRANSFORMER, POWER(DE445:US)
0 T901 1-435-314-11 TRANSFORMER, POWER(DE445:AEP,UK,CIS)
0 T901 1-435-562-11 TRANSFORMER, POWER(DE545:TW)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
