36
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
A-4428-428-A DISPLAY BOARD, COMPLETE (DE445:US)
************************
A-4428-438-A DISPLAY BOARD, COMPLETE (DE545:US)
************************
A-4428-458-A DISPLAY BOARD, COMPLETE (SE501)
************************
A-4428-464-A DISPLAY BOARD, COMPLETE (DE445:CND)
************************
A-4428-466-A DISPLAY BOARD, COMPLETE
************************
(DE445:AEP,UK,CIS)
A-4428-468-A DISPLAY BOARD, COMPLETE (DE545:CND)
************************
A-4428-471-A DISPLAY BOARD, COMPLETE
************************
(DE545:AEP,UK,CIS)
A-4428-479-A DISPLAY BOARD, COMPLETE (DE545:TW,E,PX)
************************
A-4428-482-A DISPLAY BOARD, COMPLETE (DE545:CH,SP,MY)
************************
A-4428-492-A DISPLAY BOARD, COMPLETE (DE545:AUS)
************************
* 3-386-245-12 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C011 1-164-159-11 CERAMIC 0.1uF 50V
C100 1-164-159-11 CERAMIC 0.1uF 50V
C101 1-164-159-11 CERAMIC 0.1uF 50V
C102 1-104-905-11 CAPACITOR 0.22F 5.5V
C103 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-164-159-11 CERAMIC 0.1uF 50V
C111 1-124-589-11 ELECT 47uF 20% 16V
C112 1-124-465-00 ELECT 0.47uF 20% 50V
C113 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-164-159-11 CERAMIC 0.1uF 50V
C116 1-164-159-11 CERAMIC 0.1uF 50V
C117 1-124-261-00 ELECT 10uF 20% 50V
C119 1-124-261-00 ELECT 10uF 20% 50V
C120 1-164-159-11 CERAMIC 0.1uF 50V
C121 1-128-809-11 CERAMIC 100PF 5% 50V
C122 1-128-809-11 CERAMIC 100PF 5% 50V
C123 1-164-159-11 CERAMIC 0.1uF 50V
C124 1-128-809-11 CERAMIC 100PF 5% 50V
C125 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C126 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C127 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C128 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C129 1-124-261-00 ELECT 10uF 20% 50V
C130 1-164-159-11 CERAMIC 0.1uF 50V
C131 1-124-261-00 ELECT 10uF 20% 50V
C132 1-164-159-11 CERAMIC 0.1uF 50V
C134 1-164-159-11 CERAMIC 0.1uF 50V
C198 1-164-159-11 CERAMIC 0.1uF 50V
C199 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP100 1-794-028-11 BOARD TO BOARD PIN 4P
* CNP102 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CNP103 1-794-001-11 CONNECTOR 20P
CNP104 1-794-002-11 CONNECTOR 13P(EXCEPT AEP,UK,CIS)
CNP104 1-794-003-11 CONNECTOR 15P(AEP,UK,CIS)
* CNP106 1-564-594-11 PLUG, CONNECTOR 15P
* CNP107 1-564-521-11 PLUG, CONNECTOR 6P
CNP110 1-794-028-11 BOARD TO BOARD PIN 4P
< CONNECTOR >
* CNS101 1-568-449-11 HOUSING, CONNECTOR(PC BOARD)3P
* CNS105 1-695-808-11 CONNECTOR, PC BOARD 8P
< DIODE >
D002 8-719-046-39 DIODE SEL5821A-TP15(MODE)
D003 8-719-046-39 DIODE SEL5821A-TP15(2 CH)
D004 8-719-046-39 DIODE SEL5821A-TP15(A.F.D)
D005 8-719-046-39 DIODE SEL5821A-TP15(BASS/TREBLE)
D006 8-719-046-39 DIODE SEL5821A-TP15(JOG)
D007 8-719-046-39 DIODE SEL5821A-TP15(LEVEL)
D008 8-719-046-39 DIODE SEL5821A-TP15(SUR)
D009 8-719-046-39 DIODE SEL5821A-TP15(SET UP)
D010 8-719-046-39 DIODE SEL5821A-TP15(NAME)
D011 8-719-072-82 DIODE SELU5E20C-STP15(MULTICHANNEL
DECODING)
D012 8-719-313-50 DIODE SEL6810A-TH12(BASS BOOST)
D013 8-719-313-50 DIODE SEL6810A-TH12(TONE)
D014 8-719-046-37 DIODE SEL5820A-TH8F(DIGITAL)
D100 8-719-911-19 DIODE 1SS133T-72
D101 8-719-911-19 DIODE 1SS133T-72
D102 8-719-911-19 DIODE 1SS133T-72
D103 8-719-911-19 DIODE 1SS133T-72
D104 8-719-911-19 DIODE 1SS133T-72(DE545,SE501)
D109 8-719-911-19 DIODE 1SS133T-72
D110 8-719-911-19 DIODE 1SS133T-72
< FERRITE BEAD >
FB100 1-412-473-31 FERRITE 0UH
< FILTER >
FL101 1-517-929-11 TUBE, FLUORESCENT INDICATOR
< TERMINAL >
* G791 1-537-738-21 TERMINAL, EARTH
< IC >
IC101 8-759-332-18 IC GP1U27XB(REMOTE SENSOR)
IC102 8-759-656-88 IC MB90553ABPF-G-158-BND
IC103 8-759-463-11 IC MSC1162AGS-BK
