Sony STR-DE545 - Page 38

38
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R138 1-247-807-31 CARBON 100 5% 1/4W
R139 1-247-807-31 CARBON 100 5% 1/4W
R140 1-247-807-31 CARBON 100 5% 1/4W
R141 1-247-807-31 CARBON 100 5% 1/4W
R142 1-247-807-31 CARBON 100 5% 1/4W
R143 1-247-807-31 CARBON 100 5% 1/4W
R144 1-249-429-11 CARBON 10K 5% 1/4W
R145 1-247-807-31 CARBON 100 5% 1/4W
R146 1-247-807-31 CARBON 100 5% 1/4W
R147 1-247-807-31 CARBON 100 5% 1/4W
R148 1-247-807-31 CARBON 100 5% 1/4W
R149 1-247-807-31 CARBON 100 5% 1/4W
R150 1-247-807-31 CARBON 100 5% 1/4W
R151 1-247-807-31 CARBON 100 5% 1/4W
R152 1-247-807-31 CARBON 100 5% 1/4W
R153 1-247-807-31 CARBON 100 5% 1/4W
R154 1-249-429-11 CARBON 10K 5% 1/4W
R161 1-249-441-11 CARBON 100K 5% 1/4W
R162 1-249-441-11 CARBON 100K 5% 1/4W
R163 1-249-441-11 CARBON 100K 5% 1/4W
R164 1-249-441-11 CARBON 100K 5% 1/4W
R165 1-249-437-11 CARBON 47K 5% 1/4W
R175 1-249-393-11 CARBON 10 5% 1/4W F
(DE545,SE501)
R176 1-249-429-11 CARBON 10K 5% 1/4W
(DE545,SE501)
R177 1-249-425-11 CARBON 4.7K 5% 1/4W F
R178 1-249-429-11 CARBON 10K 5% 1/4W
(DE445)
R179 1-249-429-11 CARBON 10K 5% 1/4W
R187 1-249-429-11 CARBON 10K 5% 1/4W
R188 1-249-429-11 CARBON 10K 5% 1/4W
R189 1-249-429-11 CARBON 10K 5% 1/4W
R198 1-249-385-11 CARBON 2.2 5% 1/6W F
R199 1-249-385-11 CARBON 2.2 5% 1/6W F
< VARIABLE RESISTOR >
RV102 1-418-773-11 ENCODER, ROTARY(MASTER VOLUME)
< SWITCH >
S110 1-771-410-21 SWITCH, TACTILE(<)
S111 1-771-410-21 SWITCH, TACTILE(CHINEMA STUDIO C)
S112 1-771-410-21 SWITCH, TACTILE(SUR)
S113 1-771-410-21 SWITCH, TACTILE(ENTER)
S114 1-771-410-21 SWITCH, TACTILE(BASS/TREBLE)
S115 1-771-410-21 SWITCH, TACTILE(NAME)
S116 1-771-410-21 SWITCH, TACTILE(SET UP)
S120 1-771-410-21 SWITCH, TACTILE(>)
S121 1-771-410-21 SWITCH, TACTILE(CHINEMA STUDIO B)
S122 1-771-410-21 SWITCH, TACTILE(CHINEMA STUDIO A)
S123 1-771-410-21 SWITCH, TACTILE(AUX)
S124 1-771-410-21 SWITCH, TACTILE(DVD/LD)
S125 1-771-410-21 SWITCH, TACTILE(2 CH)
S126 1-771-410-21 SWITCH, TACTILE(MODE)
S127 1-771-410-21 SWITCH, TACTILE(TUNER)
S128 1-771-410-21 SWITCH, TACTILE(CD)
S129 1-771-410-21 SWITCH, TACTILE(DISPLAY)
S130 1-771-410-21 SWITCH, TACTILE(DIMMER)
S131 1-771-410-21 SWITCH, TACTILE(A.F.D)
S132 1-771-410-21 SWITCH, TACTILE(INPUT MODE)
S133 1-771-410-21 SWITCH, TACTILE(5.1CH INPUT)
S134 1-771-410-21 SWITCH, TACTILE(LEVEL)
S135 1-771-410-21 SWITCH, TACTILE(TV/SAT)
S136 1-771-410-21 SWITCH, TACTILE(MD/TAPE)
S137 1-771-410-21 SWITCH, TACTILE(VIDEO)
< VIBRATOR >
X101 1-781-356-21 VIBRATOR, CERAMIC (16MHz)
**************************************************************
1-676-786-11 HEADPHONE BOARD
*****************
< CONNECTOR >
CNP792 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< JACK >
J791 1-750-733-11 JACK (LARGE TYPE)(PHONES)
(EXCEPT CH,TW,SP,MY)
J791 1-750-735-11 JACK (LARGE TYPE)(PHONES)(CH,TW,SP,MY)
**************************************************************
1-676-787-11 JOG BOARD
**********
< VARIABLE RESISTOR >
RV101 1-418-817-11 ENCODER (ROTARY)(JOG)
**************************************************************
A-4428-423-A MAIN BOARD, COMPLETE (DE445:US)
**********************
A-4428-429-A MAIN BOARD, COMPLETE (DE545:US,SE501)
*********************
A-4428-463-A MAIN BOARD, COMPLETE (DE445:CND)
*********************
A-4428-465-A MAIN BOARD, COMPLETE (DE445:AEP,UK,CIS)
*********************
A-4428-467-A MAIN BOARD, COMPLETE (DE545:CND,E,PX)
*********************
A-4428-469-A MAIN BOARD, COMPLETE (DE545:AEP,UK,CIS)
*********************
A-4428-490-A MAIN BOARD, COMPLETE
*********************
(DE545:CH,TW,SP,MY,AUS)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C303 1-128-815-11 CERAMIC 330PF 5% 50V
(AEP,UK,CIS)
C304 1-126-961-11 ELECT 2.2uF 20.00% 50V
(AEP,UK,CIS)
C305 1-164-159-11 CERAMIC 0.1uF 50V
(AEP,UK,CIS)
DISPLAY
HEADPHONE
JOG MAIN
