STR-DE495/DE595
1) Depending on the sound field settings and the
source, there may be no sound output.
2) Measured under the following conditions:
Area code Power requirements
E2, AUS 240 V AC, 50 Hz
SP, MY, AEP, UK, AR, 230 V AC, 50 Hz
KR
TW 110 V AC, 60 Hz
Frequency response
MULTI CH IN 10 Hz – 50 kHz
(STR-DE595 only), CD +0.5/–2 dB (with sound
(STR-DE495 only), field and tone bypassed)
MD/TAPE, DVD,
VIDEO 1, 2
CD/SACD (STR-DE595 10 Hz – 70 kHz
only) +0.5/–2 dB (with sound
field and tone bypassed)
Inputs (Analog)
MULTI CH IN Sensitivity: 500 mV
(STR-DE595 only), CD/ Impedance: 50 kilohms
SACD (STR-DE595 S/N
3)
: 96 dB
only), CD (STR-DE495 (A, 500 mV
4)
)
only), MD/TAPE, DVD,
VIDEO 1, 2
3) INPUT SHORT (with sound field and tone
bypassed).
4) Weighted network, input level.
Inputs (Digital)
DVD (Coaxial) Sensitivity: –
Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
CD/SACD (Optical) Sensitivity: –
(STR-DE595 only), Impedance: –
VIDEO 2 (Optical) S/N: 100 dB
(A, 20 kHz LPF)
Outputs
MD/TAPE (OUT), Voltage: 500 mV
VIDEO1 Impedance: 10 kilohms
(AUDIO OUT)
SUB WOOFER Voltage: 2 V
Impedance: 1 kilohms
Tone
Gain levels: ±6 dB, 1 dB step
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna terminals 75 ohms, unbalanced
Intermediate Frequency 10.7 MHz
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75 ohms
Usable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz,
+0.5/–2 dB
Selectivity 60 dB at 400 kHz
AM tuner section
Tuning range
Models of area code US, CND
With 10-kHz tuning scale: 530 – 1710 kHz
5)
With 9-kHz tuning scale: 531 – 1710 kHz
5)
Models of area code E2
With 10-kHz tuning scale: 530 – 1610 kHz
5)
With 9-kHz tuning scale: 531 – 1602 kHz
5)
Models of area code AUS, SP, AEP, UK, TW, KR
With 9-kHz tuning scale: 531 – 1602 kHz
Models of area code MX, AR
With 10-kHz tuning scale: 530 – 1610 kHz
Antenna Loop antenna
Intermediate Frequency 450 kHz
Usable sensitivity 50 dB/m (at 1,000 kHz or
999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5 % (50 mV/m, 400 Hz)
Selectivity
At 9 kHz: 35 dB
At 10 kHz: 40 dB
5) You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off
the receiver. Hold down PRESET TUNING + and
press ?/1 . All preset stations will be erased when
you change the tuning scale. To reset the scale to
10 kHz (or 9 kHz), repeat the procedure.
Video section
Inputs
Video: 1 Vp-p, 75 ohms
Component Video (STR-DE595 only, except for
models of area code AEP, UK):
Y: 1 Vp-p, 75 ohms
PB/B-Y: 0.7 Vp-p, 75 ohms
PR/R-Y: 0.7 Vp-p, 75 ohms
Outputs
Video: 1 Vp-p, 75 ohms
Component Video (STR-DE595 only, except for
models of area code AEP, UK):
Y: 1 Vp-p, 75 ohms
PB/B-Y: 0.7 Vp-p, 75 ohms
PR/R-Y: 0.7 Vp-p, 75 ohms
General
Power requirements
Area code Power requirements
US, CND, MX 120 V AC, 60 Hz
AEP, UK 230 V AC, 50/60 Hz
SP, MY, KR, AR 220 – 230 V AC, 50/60 Hz
E2 120/220/240 V AC, 50/60 Hz
TW 110 V AC, 50/60 Hz
AUS 240 V AC, 50Hz
Power consumption
Area code Power consumption
US, MX STR-DE595: 210 W
CND STR-DE595: 310 VA
AEP, UK, TW, KR STR-DE595: 210 W
STR-DE495: 180 W
SP, MY STR-DE595: 180 W
AUS, E2, AR STR-DE595: 210 W
Power consumption (during standby mode)
0.3 W
Dimensions 430 × 145 × 298 mm
(16 7/8 × 5 6/8 × 11 6/8 in.)
including projecting parts
and controls
Mass (Approx.) STR-DE595: 7.5 kg (16 lb 9 oz)
STR-DE495: 7.2 kg (15 lb 14 oz)
Supplied accessories
FM wire antenna (1)
AM loop antenna (1)
Remote commander RM-U306A (1)
R6 (size-AA) batteries (2)
Design and specifications are subject to change
without notice.
•Abbreviation
CND : Canadian model
AUS: Australian model
MX : Mexican model
SP : Singapore model
E2 : AC 120 V area in E model
AR : Argentine model
KR : Korean model
TW : Taiwan model
Ver 1.1
