* You can watch the selected input image when you
connect the MONITOR OUT jack to a TV monitor
(page 24).
E AUDIO INPUT/OUTPUT section
AUDIO IN/
OUT jack
Connects to an MD
deck or CD player,
etc. (page 21).
MULTI
CHANNEL
INPUT jack
Connects to a
Super Audio CD
player or DVD
player which has
an analog audio
jack for 5.1
channel sound
(page 20).
PRE OUT
jack
Connects to an
external power
amplifier.
F ANTENNA section
FM
ANTENNA
Connects to the FM
wire antenna
supplied with this
receiver (page 29).
AM
ANTENNA
Connects to the AM
loop antenna
supplied with this
receiver (page 29).
XM
ANTENNA
Connects to the XM
Connect-and-Play
antenna (not
supplied) (page 65).
White (L)
Red (R)
White (L)
Red (R)
Black
White (L)
Red (R)
