Sony STR-DG710 - IC Pin Descriptions (HDMI TX Continued); IC3513 Pinout Details (61-80)

63
STR-DG710
Pin No . Pin Name I/O Pin Descr iption
61 to 65 D13 to D9 I Serial data input 13 to 9 from HDMI RX and video processor.
66 IDCK I Output data clock signal input from HDMI RX.
67 to 70 D8 to D5 I Serial data input 8 to 5 from HDMI RX and video processor.
71 IOVCC — Power supply pin (+3.3 V)
72 IOGND — Ground pin
73 CGND — Ground pin
74 CVCC18 — Power supply pin (+1.8 V)
75 to 79 D4 to D0 I Serial data input 4 to 0 from HDMI RX and video processor.
80 DE I Data enable signal input from HDMI RX.
