Sony STR-DG710 - Electrical Parts List: Resistors and Transistors; Resistors and Transistors (Main Board)

71
STR-DG710
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IC1301 8-759-825-15 IC LC89056W-E
IC1302 8-759-595-15 IC TC74ACT153F(EL)
IC1303 8-759-096-87 IC TC7WU04FU(TE12R)
IC1351 6-600-466-01 IC TORX147L(SONY) (DIGITAL
VIDEO 1 IN (OPTICAL))
IC1354 6-600-466-01 IC TORX147L(SONY) (DIGITAL
SAT IN (OPTICAL))
IC1401 6-707-608-01 IC PCM1803DBR
IC1403 8-759-710-97 IC NJM4565M-D
IC1404 8-759-710-97 IC NJM4565M-D
IC1405 8-759-710-97 IC NJM4565M-D
IC1406 8-759-710-97 IC NJM4565M-D
IC1452 6-708-785-01 IC PCM1609APT
IC1501 6-705-900-01 IC CXD9718BQ
IC1502 6-709-278-01 IC IS61WV6416BLL-12TLI
IC1503 8-759-546-74 IC TC7WH157FU(TE12R)
IC1700 8-759-058-62 IC TC7S08FU(TE85R)
IC1710 8-759-277-63 IC TC7W14FU(TE12R)
IC1901 6-701-887-02 IC SI-3004KWF
IC1902 8-759-231-56 IC TA7809S
IC1904 6-705-468-01 IC BA33BC0FP-E2
IC1906 6-707-745-10 IC SI-3050KM-TL
IC1907 6-807-248-01 IC MB91353APMT-G-112E1
< JACK >
J1301 1-793-446-21 JACK, PIN 1P (DIGITAL DVD IN (COAXIAL))
< CONNECTOR >
J1311 1-817-615-21 CONNECTOR, BOARD TO BOARD 18P (DMPORT)
< JUMPER RESISTOR >
JR1000 1-211-950-11 SHORT CHIP 0
JR1001 1-211-950-11 SHORT CHIP 0
JR1002 1-211-950-11 SHORT CHIP 0
JR1003 1-211-950-11 SHORT CHIP 0
JR1004 1-216-864-11 SHORT CHIP 0 (EXCEPT MY,SP,TH)
JR1005 1-216-864-11 SHORT CHIP 0
JR1006 1-211-950-11 SHORT CHIP 0
JR1008 1-216-864-11 SHORT CHIP 0
JR1009 1-211-950-11 SHORT CHIP 0
JR1020 1-216-864-11 SHORT CHIP 0
JR1511 1-400-862-11 BEAD, FERRITE
JW1700 1-216-864-11 SHORT CHIP 0
< FERRITE BEAD >
L1403 1-400-862-11 BEAD, FERRITE
< TRANSISTOR >
Q1701 8-729-620-10 TRANSISTOR 2SA1602TP-1EF
Q1702 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q1703 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q1704 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1010 1-216-809-11 METAL CHIP 100 5% 1/10W
R1011 1-216-809-11 METAL CHIP 100 5% 1/10W
R1012 1-216-809-11 METAL CHIP 100 5% 1/10W
R1013 1-216-809-11 METAL CHIP 100 5% 1/10W
R1014 1-216-809-11 METAL CHIP 100 5% 1/10W
R1015 1-216-809-11 METAL CHIP 100 5% 1/10W
R1035 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1039 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1041 1-216-809-11 METAL CHIP 100 5% 1/10W
R1042 1-216-809-11 METAL CHIP 100 5% 1/10W
R1044 1-216-809-11 METAL CHIP 100 5% 1/10W
R1050 1-216-809-11 METAL CHIP 100 5% 1/10W
R1058 1-216-813-11 METAL CHIP 220 5% 1/10W
(AEP,UK)
R1059 1-216-813-11 METAL CHIP 220 5% 1/10W
(AEP,UK)
R1061 1-216-809-11 METAL CHIP 100 5% 1/10W
R1062 1-216-809-11 METAL CHIP 100 5% 1/10W
R1065 1-216-809-11 METAL CHIP 100 5% 1/10W
R1066 1-216-809-11 METAL CHIP 100 5% 1/10W
R1067 1-216-809-11 METAL CHIP 100 5% 1/10W
R1068 1-216-809-11 METAL CHIP 100 5% 1/10W
R1072 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1073 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1076 1-216-809-11 METAL CHIP 100 5% 1/10W
R1077 1-216-809-11 METAL CHIP 100 5% 1/10W
R1078 1-216-809-11 METAL CHIP 100 5% 1/10W
R1083 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1085 1-216-809-11 METAL CHIP 100 5% 1/10W
R1087 1-216-809-11 METAL CHIP 100 5% 1/10W
(US,CND)
R1088 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1089 1-216-809-11 METAL CHIP 100 5% 1/10W
(US,CND)
R1093 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1096 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1106 1-216-809-11 METAL CHIP 100 5% 1/10W
R1107 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1108 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1110 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1111 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1112 1-216-809-11 METAL CHIP 100 5% 1/10W
R1114 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1117 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1118 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1120 1-216-809-11 METAL CHIP 100 5% 1/10W
R1121 1-216-809-11 METAL CHIP 100 5% 1/10W
R1122 1-216-809-11 METAL CHIP 100 5% 1/10W
R1123 1-216-809-11 METAL CHIP 100 5% 1/10W
R1124 1-216-809-11 METAL CHIP 100 5% 1/10W
R1125 1-216-809-11 METAL CHIP 100 5% 1/10W
R1126 1-216-809-11 METAL CHIP 100 5% 1/10W
R1129 1-216-809-11 METAL CHIP 100 5% 1/10W
R1134 1-216-809-11 METAL CHIP 100 5% 1/10W
R1135 1-216-809-11 METAL CHIP 100 5% 1/10W
R1140 1-216-809-11 METAL CHIP 100 5% 1/10W
R1143 1-216-809-11 METAL CHIP 100 5% 1/10W
R1144 1-216-809-11 METAL CHIP 100 5% 1/10W
R1150 1-216-809-11 METAL CHIP 100 5% 1/10W
R1151 1-216-809-11 METAL CHIP 100 5% 1/10W
R1152 1-216-809-11 METAL CHIP 100 5% 1/10W
DIGITAL
Ver. 1.1
